EAO Capacitive Switch Latching NO Illuminated Green IO-Link IP69K Stainless Steel 32V dc 200mA 84-ACKS-B12-04BB

The EAO 84-ACKS-B12-04BB is a capacitive switch featuring latching NO operation with illuminated green LED and IO-Link output technology. It is engineered with a stainless steel SUS 316L front bezel, ensuring excellent mechanical durability and corrosion resistance, suited for demanding industrial environments.

This high-performance switch is capable of operating within a temperature range of -30°C to 65°C, making it suitable for diverse applications including industrial automation, manufacturing machines, process control, and more. Its IP69K rating guarantees protection against ingress of water and dust, even under high pressure and steam cleaning, ideal for hygienic or harsh settings.

Equipped with a round push button operator, the switch provides reliable tactile feedback with a latching mechanism controlled through IO-Link interface, allowing precise and programmable operation. The green LED illumination offers clear visual status indication, with additional animated illumination options configurable via IO-Link, enhancing versatility across applications.

The unit supports a maximum input voltage of 32V dc and a current rating of 200mA, fitting standard industrial control system specifications. Certification compliance includes CE, RoHS, and CSA standards, ensuring adherence to global safety and environmental regulations.

This model includes an M12 connector to facilitate simple and secure device integration in automated and industrial systems. The front bezel material is stainless steel SUS 316L, designed for longevity and resilience in tough operating conditions.

Common use cases include electrical and automation systems, control panels, factory automation machines, and other demanding environments requiring robust, innovative capacitive switches.

Shop the EAO range for reliable industrial Capacitive Switches and discover high-quality components suitable for complex automation and control systems. The switch features a round push button operator for intuitive use.

Illuminated with a green LED and has additional preconfigured red and rotary LED colors. Housing is made from robust stainless steel SUS 316L providing durability and corrosion resistance. Operational in temperatures ranging from -30°C to 65°C with an IP69K ingress protection rating.

Supports IO-Link output type and latching switch operation logic. Maximum input voltage is 32V dc with a current rating up to 200mA. Complies with CE, RoHS, and CSA standards for quality and safety. Includes an M12 connector for secure industrial connectivity.
