Fibox Flanged EK Series Grey Grey Lid Polycarbonate Enclosure IP66 IP67 IK08 180mm x 280mm x 280mm EKOE 180 G + EKOVT

Free Delivery in India | Lowest Global Shipping Charges

Fibox Flanged EK Series Grey Grey Lid Polycarbonate Enclosure IP66 IP67 IK08 180mm x 280mm x 280mm EKOE 180 G + EKOVT

Name: Fibox Flanged EK Series Grey Grey Lid Polycarbonate Enclosure IP66 IP67 IK08 180mm x 280mm x 280mm EKOE 180 G + EKOVT
Brand: Fibox
SKU: 170424
Price: 241.62 USD
Availability: InStock



Category Flanged Polycarbonate Enclosure Brand Fibox Condition New

Specifications

Country of Origin	Finland
Brand	Fibox
Colour	Grey
Body Material	Polycarbonate
Model	EKOE 180 G + EKOVT
IP Rating	IP66, IP67
Series	EK
External Width	280mm
External Height	180mm
Shielding	Unshielded
Standards/Approvals	GL, FIMKO, UL, Lloyds, GOST R
External Length	280mm
IK Rating	IK08
Gasket Material	Polyurethane

Key Features

Constructed from durable polycarbonate material for robust electrical equipment housing.
Equipped with a grey lid and body with polyurethane gasket for secure sealing.
Complies with IP66 and IP67 ingress protection standards to prevent dust and water ingress.
Impact resistant to IK08 standard ensuring mechanical protection.
Suitable for harsh industrial environments requiring chemical resistance and UV stability.
Supplied with chassis plate, screws, and PUR/EPDM gasket for complete assembly.
RoHS compliant, halogen-free, and temperature rated from -40°C to +120°C (+80°C continuous).

Product Description

Fibox EKOE 180 G + EKOVT Flanged Polycarbonate Enclosure is designed to house electrical and automation equipment securely in industrial and commercial applications. Made from specially formulated polycarbonate material, it offers exceptional impact resistance, self-extinguishing properties, and resistance to acids and alkalis.

The enclosure measures 180 mm in height, 280 mm in width, and 280 mm in length, making it suitable for compact installations. Its grey body and lid, sealed with a durable polyurethane gasket, provide IP66 and IP67 ingress protection, safeguarding sensitive electronics from dust and water ingress.

This product meets the IK08 impact rating, ensuring robust mechanical protection against external impacts, making it reliable in demanding environments. Additionally, it is RoHS compliant and halogen-free, supporting environmentally responsible manufacturing standards.

The enclosure is UV resistant, complying with UL 508 standards, and supports a temperature range from -40°C to +120°C, with continuous usage suitability up to +80°C. It is supplied complete with a chassis plate, screws, and a PUR/EPDM gasket for easy and secure installation.

Industry approvals include UL, GL, FIMKO, Lloyds, and GOST R certification. Optional accessories such as gland plates and extension frames are available separately to enhance versatility and mounting options.

Constructed from polycarbonate for chemical and impact resistance. Protection rated at IP66/IP67 against dust and water. Meets IK08 impact resistance standards. Includes chassis plate, lid, screws, and gasket for secure assembly.

Temperature tolerant from -40°C to +120°C, UL94-V2 flammability rating. RoHS compliant and halogen-free design. Certified with multiple industrial standards ensuring quality and safety. Suitable for electrical, automation, HVAC, and industrial control applications.

This Fibox EK series enclosure is ideal for protecting control panels, instrumentation, and industrial electronics in harsh environments. Browse more electrical enclosures from Fibox and related products on EnvMart for comprehensive automation solutions.
