Fibox AB Series Grey Light Grey Lid ABS Electrical Enclosure, IP67, IP66, IK07, 101 mm x 360 mm x 160 mm AB 163610 ENCLOSURE

Fibox AB 163610 ENCLOSURE is a high-quality ABS electrical enclosure designed for robust protection of electrical and automation equipment. It features an IP67 and IP66 rated casing ensuring dust tight and water immersion resistance, along with IK07 impact resistance for mechanical protection.

The enclosure measures 101 mm in height, 360 mm in length, and 160 mm in width, with a grey body and light grey lid finished in RAL 7035 color. The construction includes a polyurethane gasket that guarantees effective sealing and protection against environmental ingress.

Designed to house DIN rail mounted terminal blocks and various process sensors, it incorporates a mounting plate to facilitate installation. The enclosure is fully electrically insulated and halogen free, complying with UL94HB flammability standards, making it safe for industrial use.

Additional features include stainless steel cover screws that remain captive yet removable, injection-moulded plastic threads for corrosion resistance, and a smooth outer surface with no gate marks, ideal for labelling or decals. Multiple low height mounting points maximize usable internal space, and mounting holes are positioned outside the gasket area to preserve water tightness.

The Fibox AB series complies with multiple international standards, including NEMA types 1, 4, 4X, 12, and 13 for the USA, ULc for Canada, EN 50298 and EN 60950 for Europe, and AS 3132-1991 for Australia.

Constructed from durable ABS material for reliable protection. Features light grey lid and grey body conforming to RAL 7035 color standard. Equipped with polyurethane gasket providing superior sealing against dust and water.

Includes mounting plate and supports DIN rail internal mounting. Designed to be electrically insulated and halogen free with UL94HB flammability rating. Suitable for industrial, automation, and electrical equipment housings.

Meets international standards including NEMA types, ULc, EN 50298, EN 60950, and AS 3132-1991. Cover screws are stainless steel, captive, and fasten easily preventing corrosion.

This enclosure is suitable for industrial, electrical automation, manufacturing, and process control applications requiring durable and sealed housing solutions. Explore more Electrical Enclosures and accessories for diverse industrial needs at EnvMart.
