SMC Pneumatic Solenoid Valve Pilot Actuation VZA5000 Series G 1/8 Port Size, 0.7 Mpa Pressure EVZA5220-01F

SMC EVZA5220-01F pneumatic solenoid valve pilot actuation is part of the VZA5000 Series designed for precise control in pneumatic systems. This valve is engineered for inline mounting with a base, body ported configuration to suit various industrial automation needs.

The valve features a port size of G 1/8 and includes 5 ports with 3 operating positions, delivering flexibility in control operations. It offers a maximum operating pressure of 0.7 Mpa and pilot pressures ranging from 0.1 Mpa minimum to 0.7 Mpa maximum, which supports stable and reliable pneumatic functioning.

With a maximum flow rate of 534.9 NL/min, this valve effectively manages pneumatic flow for applications in manufacturing, mechanical systems, HVAC, and fluid power equipment. The valve operates reliably at temperatures up to 60°C, making it suitable for demanding industrial environments.

Multiple valve functions such as 3 position exhaust centre, 3 position pressure centre, 2 position double check, and 3 position closed configurations provide versatile application options. The pilot actuation reduces power consumption, enabling direct operation by PLC systems, increasing energy efficiency and control accuracy.

It features a manual pulse control and a non-locking manual override for ease of maintenance and manual operation if needed. Note that the connector for this valve is to be ordered separately, allowing customization according to specific system requirements.

The valve is manufactured in France, reflecting high-quality production standards. It is ideal for industrial automation, pneumatic control, and fluid power systems in sectors such as manufacturing, water treatment, and mechanical machinery.

Features pilot actuation suitable for pneumatic control systems. Equipped with base, body ported mount type for inline mounting. Maximum operating pressure of 0.7 Mpa with a minimum pilot pressure of 0.1 Mpa. Supports multiple valve functions including 3 position exhaust centre and 2 position single solenoid.

Maximum flow rate of 534.9 NL/min ensures efficient pneumatic flow handling. Operates reliably up to a maximum temperature of 60°C. Designed for industrial applications requiring precise pneumatic control. Connector to be ordered separately for customizable configurations.

Manufactured in France ensuring quality standards. Explore the range of Pneumatic Solenoid Valves and related industrial valve components available at EnvMart for efficient and reliable fluid power solutions.
