Honeywell Technologies Short Lever Micro Switch, Solder Terminal, 100mA, 250 V, SPDT, IP40 ZM110D10B01

Honeywell ZM110D10B01 Short Lever Micro Switch is a compact and precise subminiature electromechanical actuator designed for efficient signal switching within automation and electrical control systems. Operating at 250 V AC and rated for 100 mA contact current, this switch provides reliable performance in low-power circuits.

The device features a short lever actuator that delivers quick-transition tactile feedback, ideal for mechanical linkages and cam follower interfaces. Its solder terminal connections ensure secure mounting and reliable electrical integration on printed circuit boards or wired assemblies.

Constructed with a durable PBT housing material, the switch is rated for IP40 ingress protection, making it suitable for environments with moderate dust exposure. It supports an extended temperature operating range from -40°C to 125°C, enabling deployment in varied industrial, laboratory, and commercial applications.

This model offers a single-pole double throw (SPDT) contact configuration, supporting simple yet versatile circuit selection. The compact size with dimensions of 19.8mm length, 10.2mm depth, and 6.4mm width facilitates space-saving installation within confined assemblies.

Designed for longevity, the switch is rated for 1,000,000 mechanical operations ensuring dependable use in intermittent control feedback roles. The ZM110D10B01 complies with international approvals including CE, REACH, ENEC, UL, cUL, CQC, and adheres to RoHS standards, reflecting its suitability for regulatory compliance.

Typical applications include limit-switch feedback in automated machinery, sensing and interlock functions in consumer appliances, and use within control panels requiring compact and responsive signal switches. Its reliable performance in low-power control and sensing circuits makes it ideal for prototyping and industrial automation systems.

Set contains 1 Pc Honeywell Technologies ZM110D10B01 Short Lever Micro Switch with solder terminals and SPDT contact configuration suitable for low voltage and signal switching tasks.

Explore the Electronics & Electricals category for more switches and reliable industrial components. Features a short lever actuator for tactile and quick-transition contact action. Equipped with solder terminals for reliable PCB and wire connections.

Rated for 100 mA contact current suitable for low-power control circuits. Operating temperature range from -40°C to 125°C ensures versatility. Constructed with durable PBT housing material and IP40 ingress protection. Provides a single-pole double throw (SPDT) contact configuration.

Compact dimensions allow for space-saving installations in assemblies. Mechanical life rated for 1,000,000 operations for reliable performance. Complies with multiple industrial standards including CE, REACH, UL, and RoHS.
