TDK-Lambda CC-E Dual Output DC/DC Converter 12V DC/130mA, 9-18V Input, 3W Surface Mount CC3-1212DR-E

TDK-Lambda CC3-1212DR-E is a dual output DC/DC converter designed for converting DC voltages within electronic, industrial, and telecommunication equipment. It offers reliable isolated voltage conversion with a total output power of 3 watts, making it suitable for powering circuits requiring dual ±12 V supplies.

The compact surface mount package facilitates easy integration into printed circuit boards where space constraints exist. With a wide input voltage range from 9 V to 18 V DC, it accommodates varying power supply conditions efficiently. The isolation voltage of 500 V provides essential electrical isolation, improving safety and reducing noise interference between input and output circuits.

Operating within a temperature range of -40°C to 85°C, the converter maintains stable performance in demanding environments. Its efficiency rating of 81% helps reduce energy losses and heat dissipation, contributing to system longevity. The converter is RoHS compliant, ensuring it meets environmental and safety regulations.

The device features dual outputs; one providing 12 V DC at 130 mA and the other -12 V DC at 130 mA, ideal for applications requiring complementary power rails. Its lightweight design of 4.5 grams and compact dimensions (26.16 mm length × 22.8 mm width × 16.6 mm depth) allow for minimal size impact on overall device design.

Applications for the CC3-1212DR-E include use in telecommunications, industrial control systems, consumer electronics, and other electronic devices requiring isolated dual voltage supplies. The surface mount package with 7 pins ensures reliable electrical connections on PCB assemblies.

Package includes the TDK-Lambda CC3-1212DR-E DC/DC converter module. This product is manufactured in Japan and backed by TDK-Lambda's quality standards. Compact surface mount package designed for space-efficient PCB integration.

Accepts input voltage range from 9 V DC to 18 V DC for versatile power supply conditions. Dual outputs provide +12 V DC at 130 mA and -12 V DC at 130 mA currents. High isolation voltage of 500 V enhances circuit safety and noise reduction.

Wide operating temperature range from -40°C to 85°C for reliable performance in harsh environments. Efficiency rated at 81 percent to optimize energy usage and reduce heat generation. RoHS compliant ensuring environmental standards and regulatory compliance.

Lightweight design weighing 4.5 grams ensures minimal load on the system. Dimensions: 26.16 mm length, 22.8 mm width, and 16.6 mm depth for compact footprint. 7-pin configuration allows secure electrical connections in surface mount applications.
