Amphenol Limited MIL Spec Circular Connector 2 Contacts Copper Alloy Straight 1.2kV 22A Box Mount Bayonet 62GB-12E10-02SN

Free Delivery in India | Lowest Global Shipping Charges

Amphenol Limited MIL Spec Circular Connector 2 Contacts Copper Alloy Straight 1.2kV 22A Box Mount Bayonet 62GB-12E10-02SN

Name: Amphenol Limited MIL Spec Circular Connector 2 Contacts Copper Alloy Straight 1.2kV 22A Box Mount Bayonet 62GB-12E10-02SN
Brand: Amphenol Limited
SKU: 163420
Price: 74.86 USD
Availability: InStock



Category Mil Spec Circular Connector Brand Amphenol Limited Condition New

Specifications

Country of Origin	United Kingdom
Voltage	1.2kV
Brand	Amphenol Limited
Orientation	Straight
Current	22A
Model	62GB-12E10-02SN
Temperature Operating Range	-55°C to 125°C
Mount Type	Box Mount
Contact Material	Copper Alloy
Series	62GB
Termination Type	Crimp
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Contact Plating	Gold
Number of Contacts	2
Contact Gender	Male
Connector Gender	Female
Shell Size	10
Military Standard	MIL-DTL-26482
Mating Type	Bayonet
Connector Size	Standard
Wire gauges and current carrying capabilities	Upto 45A and size 24 to 8 AWG wires

Key Features

This connector supports a voltage rating of 1.2kV for reliable power transmission.
It carries a current capacity of 22A suitable for medium power applications.
The shell size is 10 with a standard connector size ensuring compatibility.
Operating temperature ranges from -55°C to 125°C to withstand harsh environments.
Contacts are gold plated for enhanced corrosion resistance and reliable conductivity.
Termination type is crimp providing secure and easy wire attachment.
Mount type is box mount for fixed and robust installation.
Mating type is bayonet which ensures fast and secure connection cycles.

Product Description

Amphenol Limited 62GB-12E10-02SN MIL Spec Circular Connector is a high-reliability connector designed for industrial, military, aerospace, and demanding electronic applications. It features 2 male contacts crafted from copper alloy with gold plating to ensure excellent electrical conductivity and corrosion resistance.

The straight orientation of the connector with a box mount type and bayonet mating mechanism offers secure mechanical locking and easy assembly. The shell size 10 with standard connector dimensions enables seamless integration into existing systems following MIL-DTL-26482 specifications.

This connector is rated for a voltage of 1.2kV and a current of 22A, supporting wire gauges from 24 to 8 AWG with crimp termination type facilitating robust and stable electrical connections. It is engineered to operate reliably within a wide temperature range from -55°C up to 125°C, suitable for extreme environmental conditions encountered in industrial and military environments.

The design includes a resilient neoprene insulator and liquid-tight wire sealing grommet typical for the 62GB series, guaranteeing protection against moisture and dust ingress for enhanced durability.

This connector has 2 male contacts made of copper alloy with gold plating. Rated for 1.2kV voltage and 22A current carrying capacity. Implements MIL-DTL-26482 military standard ensuring quality and performance. Bayonet mating type provides secure and quick locking.

Box mount shell of size 10 provides stable and fixed installation. Termination is via crimp type for reliable wire connection. Operational temperature range from -55°C to 125°C suits harsh environments. Manufactured in the United Kingdom adhering to stringent quality controls.

This Amphenol Mil Spec Circular Connector series is ideal for demanding industrial, aerospace, military, and electronics applications where secure, reliable, and durable connections are critical. Browse our extensive catalogue for more connectors and related components compliant with international specifications and standards.
