Amphenol Limited MIL Spec Circular Connector Copper Alloy Straight 19 Contacts 7.5A 850V Shell Size 14 62GB-16F14-19PN-760
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 850V |
| Brand | Amphenol Limited |
| Orientation | Straight |
| Current | 7.5A |
| Model | 62GB-16F14-19PN-760 |
| Mount Type | Cable |
| Housing Material | Aluminium Alloy |
| Contact Material | Copper Alloy |
| Series | 62GB |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Gold |
| Number of Contacts | 19 |
| Contact Gender | Female |
| Connector Gender | Male |
| Shell Size | 14 |
| Military Standard | MIL-DTL-26482 |
| Mating Type | Bayonet |
| Connector Size | Standard |
| Shell Plating | Aluminium Alloy |
Key Features
- The connector supports a maximum current of 7.5 amperes and voltage rating of 850 volts.
- It features a straight orientation with a shell size of 14 and standard connector size.
- Constructed with copper alloy contacts plated in gold for optimal conductivity and corrosion resistance.
- The housing and shell plating are made from aluminium alloy ensuring robust mechanical strength.
- Suitable for temperatures ranging from -55°C to 125°C, with strain relief included for cable protection.
- Utilizes a bayonet mating type compliant with MIL-DTL-26482 military standard.
- Designed for high environmental protection and prevention of mismating due to keying features.
- Manufactured in the United Kingdom, ensuring quality and reliability.
Product Description
Amphenol Limited 62GB-16F14-19PN-760 is a MIL Spec Circular Connector specifically engineered for high-reliability applications requiring robust, durable, and high-performance connectors. This copper alloy straight connector includes 19 female contacts housed within a male connector assembly that operates at 850V and supports currents up to 7.5A. Its shell size 14 and standard connector size provide compatibility with a wide range of cable assemblies.
The connector body is crafted from aluminium alloy with aluminium alloy plating, offering mechanical strength and resistance to corrosion. Gold plating on the contacts enhances signal integrity by ensuring excellent conductivity and reducing oxidation effects. The integrated strain relief protects cables from stress during use.
Designed to meet MIL-DTL-26482 military specifications, this connector features a bayonet mating type for secure and easy locking, and includes keying to prevent mismating errors. It performs reliably in harsh environments with a rated operating temperature range from -55°C up to 125°C.
This connector is ideal for use in industrial, military, aerospace, and rugged electronic applications requiring secure, high-quality connections. The connector supports a maximum current of 7.5 amperes and voltage rating of 850 volts.
Features 19 gold plated female contacts for corrosion resistance and excellent signal transmission. Housing made of aluminium alloy with aluminium alloy plating for durability. Shell size 14 ensures compatibility with associated cable assemblies.
Operates over a wide temperature range from -55°C to 125°C ensuring stability in extreme conditions. Equipped with strain relief for cable stress protection and increased longevity. Bayonet mating type provides secure, quick connect and disconnect functionality.
Manufactured in the United Kingdom following MIL-DTL-26482 standard. Explore the range of Mil Spec Circular Connectors at EnvMart for reliable connectors that meet stringent military and industrial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector supports a maximum current of 7.5 amperes and a voltage rating of 850 volts.
It operates reliably over a temperature range from -55°C to 125°C.
This connector features 19 female contacts.
The housing is made from aluminium alloy, while the contacts are constructed from copper alloy and plated with gold for optimal conductivity.
It utilizes a bayonet mating type, which allows for secure and easy locking during connection.
Yes, it is designed to meet the MIL-DTL-26482 military standard.
The shell size of this connector is 14, which ensures compatibility with a wide range of cable assemblies.
This model features a straight orientation.
It is equipped with integrated strain relief to protect cables from stress during use.
This connector is manufactured in the United Kingdom.
The connector gender is male, while it features female contacts.
It is suitable for industrial, military, aerospace, and rugged electronic applications requiring secure connections.
