ABB Miniature Circuit Breaker 2-Pole 40A 462V AC 131V DC Screw Terminals DIN Rail Mount SD200 SD200

Free Delivery in India | Lowest Global Shipping Charges

ABB Miniature Circuit Breaker 2-Pole 40A 462V AC 131V DC Screw Terminals DIN Rail Mount SD200 SD200



Category Miniature Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	India
Range	SD200
Brand	ABB
Height	88mm
Model	SD200
Depth	88mm
IP Rating	IP20
Width	69mm
Mount Type	DIN Rail
Current Rating	40A
Series	SD200
Terminal type	Screw
Number of Poles	2
Standards/Approvals	IEC/EN 60947-3
Rated AC Voltage	462V ac
Rated DC Voltage	131V dc

Key Features

Features a 2-pole design for simultaneous circuit monitoring.
Rated current of 40 amperes to handle high electrical loads.
Supports rated AC voltage up to 462 volts and DC voltage up to 131 volts.
Durable screw terminals and DIN rail mounting for secure installation.
Compact dimensions of 69 mm (W) x 88 mm (H) x 35 mm (D) save space in panels.
Lightweight at 170 grams to reduce strain on circuits.
Operates effectively within a temperature range of -25°C to +55°C.
IP20 rating offers protection from solid objects larger than 12 mm.

Product Description

ABB SD200 SD200 Miniature Circuit Breaker, model SD200, is a 2-pole electrical protection device rated at 40A for AC voltage of 462V and DC voltage of 131V. It is designed for use in industrial automation, transportation systems, and automotive manufacturing environments where high reliability and endurance are critical.

Equipped with screw terminals and DIN rail mounting, this MCB ensures straightforward installation and maintenance. Its compact size of 69 mm width, 88 mm height, and 35 mm depth fits neatly into limited panel spaces, while the lightweight design at 170 grams minimizes mechanical stress on connected wiring.

Engineered to perform reliably within a broad temperature range from -25°C to +55°C and protected against ingress of solid objects larger than 12 mm with an IP20 rating, this device is suitable for harsh operational conditions.

Compliant with IEC/EN 60947-3 standards, the SD200 series offers a mechanical endurance exceeding 20,000 switching cycles, ensuring long service life in demanding industrial applications.

Two-pole design allows monitoring of dual circuits simultaneously. Rated for 40 amperes, ideal for complex motor and lighting circuits. Supports both AC and DC voltage ratings suitable for versatile applications. Screw terminal connection for secure wiring.

Compact and lightweight for easy integration and handling. Broad operating temperature range supports operations in diverse environments. IP20 protection rating guards against accidental contact and debris ingress. Meets international standards for quality and safety compliance.

This ABB Miniature Circuit Breaker is an excellent choice for industrial control panels, commercial buildings, and transportation electrical systems requiring reliable short circuit and overload protection. Explore more ABB products and circuit protection devices in the corresponding EnvMart category.
