APEM PCB Slide Switch SPST On-Off-On 400mA Thermoplastic TG39W000050
Specifications
| Country of Origin | France |
|---|---|
| Brand | APEM |
| Length | 10.1mm |
| Model | TG39W000050 |
| Depth | 5mm |
| Width | 12.6mm |
| Mount Type | PCB |
| Series | TG |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Switch Configuration | On-Off-On |
| Minimum Operating Temperature | -30°C |
| Terminal type | Through Hole |
| Standards/Approvals | RoHS |
| Switch Operation | On-Off-On |
| Contact DC Voltage | 20V dc |
| Switch Contact Current | 400mA |
| Mechanical Life | 30000Operations |
| Contact AC Voltage | 20V ac |
| Actuator Material | Thermoplastic |
Key Features
- The switch features a Single Pole Single Throw (SPST) contact configuration.
- It operates with an On-Off-On switch operation, suitable for various electronic applications.
- Supports a switch contact current of 400mA, handling low power circuits effectively.
- Constructed with a thermoplastic actuator material that is self-extinguishing for safety.
- Designed for PCB mount with through-hole terminal type for secure connections.
- Compact dimensions include length 10.1mm, width 12.6mm, and depth 5mm.
- Meets RoHS standards ensuring compliance with environmental regulations.
- Operational temperature range spans from -30°C minimum to 85°C maximum.
Product Description
APEM TG39W000050 PCB Slide Switch SPST On-Off-On 400mA with thermoplastic actuator material is a micro miniature slide switch designed for printed circuit board applications. This switch is part of the TG series, recognized for reliability and durable operation in automation and electrical equipment.
The device utilizes a Single Pole Single Throw (SPST) contact configuration to provide simple and effective on-off-on switching functionality suitable for various signal switching tasks. It supports a DC and AC contact voltage of 20V, with a switch contact current capacity of 400mA, ideal for low power circuit control.
Constructed with a thermoplastic body that is self-extinguishing, the switch offers enhanced safety and resistance to high temperatures up to 85°C. The actuator material provides tactile and reliable switching action over an extensive mechanical life rated at 30,000 cycles. Its compact size, with dimensions 10.1mm (L) x 12.6mm (W) x 5mm (D), is suitable for space-constrained PCB layouts.
Additional features include a through-hole terminal type for secure mounting and RoHS compliance, reflecting environmentally friendly manufacturing processes.
This PCB slide switch is suitable for industrial automation, electronic device manufacturing, laboratory instrumentation, and other low voltage control applications requiring precise and durable switching mechanisms.
The switch features a Single Pole Single Throw (SPST) contact configuration. It operates with an On-Off-On switch operation, suitable for various electronic applications. Supports a switch contact current of 400mA, handling low power circuits effectively.
Constructed with a thermoplastic actuator material that is self-extinguishing for safety. Designed for PCB mount with through-hole terminal type for secure connections. Compact dimensions include length 10.1mm, width 12.6mm, and depth 5mm.
Meets RoHS standards ensuring compliance with environmental regulations. Operational temperature range spans from -30°C minimum to 85°C maximum. Mechanical durability rated for 30,000 operations ensuring long-term reliability.
Manufactured in France, guaranteeing high-quality industrial standards. Explore the range of APEM PCB Slide Switches and other electronic switches at EnvMart for reliable industrial and laboratory applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It features a Single Pole Single Throw (SPST) contact configuration, allowing for simple on-off-on switching functionality.
The switch supports a switch contact current capacity of 400mA, making it suitable for low power circuits.
This model has compact dimensions of 10.1mm in length, 12.6mm in width, and 5mm in depth.
The operational temperature range spans from -30°C to a maximum of 85°C.
It is designed for PCB mounting with a through-hole terminal type for secure connections.
The actuator material is thermoplastic, which is self-extinguishing for enhanced safety.
It has a mechanical life rated for 30,000 operations, ensuring long-term reliability.
This model supports a contact voltage of 20V for both DC and AC applications.
Yes, it meets RoHS standards, ensuring compliance with environmental regulations.
It is suitable for industrial automation, electronic device manufacturing, and laboratory instrumentation requiring precise switching mechanisms.
It is manufactured in France, adhering to high industrial standards.
The switch operates with an On-Off-On configuration, allowing for versatile switching options.
