KEMET SPST Through Hole Reed Switch 100 mA 30 V dc OHD5R-35B
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | KEMET |
| Length | 6.7mm |
| Model | OHD5R-35B |
| Depth | 19.1mm |
| Width | 5mm |
| Mount Type | Through Hole |
| Contact Material | Nickel Iron Alloy |
| Series | OHD Thermal Guard |
| Maximum Switching Current | 100mA |
| Maximum Operating Temperature | 150°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -20°C |
| Terminal type | Wire |
| Contact Resistance | 300mΩ |
| Maximum Switching Power | 1W |
| Standards/Approvals | RoHS |
| Maximum Switching Voltage | 30V dc |
Key Features
- Utilizes nickel iron alloy contacts for durability and reliable electrical performance.
- Features a compact size with 6.7 mm length, 5 mm width, and 19.1 mm depth.
- Operates over a temperature range from -20°C to 150°C for versatile applications.
- Designed with wire terminal type and through hole mounting for secure PCB installation.
- Part of the OHD Thermal Guard series, providing thermal problem countermeasures using Thermorite® material.
- RoHS compliant ensuring compliance with environmental standards.
- High reliability and long operational life with excellent environmental durability.
- Suitable for detecting atmospheric temperatures and monitoring overheating in electronic devices.
Product Description
KEMET OHD5R-35B SPST Through Hole Reed Switch features a maximum switching current of 100 mA and maximum switching voltage of 30 V dc. This reed switch uses a nickel iron alloy contact material and is designed for through hole mounting with wire terminals, making it ideal for PCB assembly. It boasts compact dimensions of 6.7 mm length, 5 mm width, and 19.1 mm depth with an operational temperature range between -20°C and 150°C.
This product belongs to the OHD Thermal Guard series, incorporating a temperature-sensitive soft ferromagnetic substance known as Thermorite®. Its unique design effectively counters thermal problems by decreasing magnetic flux density as temperature rises, turning paramagnetic at the Curie temperature.
The switch is highly reliable for on/off applications, offering a high-speed response and long operational life. It is corrosion-proof, dust-proof, and explosion-proof, suitable for harsh industrial environments. Its compatibility extends from extremely low signals (0.1 mW or lower) to high power levels (up to 6 W), enabling simple circuit designs.
Applications include atmospheric temperature detection and overheating monitoring for power transistors, power modules, room heaters, hot gas heaters, PPCs, amplifiers, motors, hard disk drives (HDDs), floppy disk drives (FDDs), and general appliances.
Utilizes nickel iron alloy contacts for secure electrical connection. Compact through hole mounting design ensures ease of integration into PCB layouts. Wide operating temperature range for versatile usage in various conditions.
High reliability and environmental durability with RoHS compliance. Advanced thermal guard design provides effective temperature monitoring capabilities. Resistant to dust, explosion, and corrosion for longer service life.
Supports low to high power signal compatibility for multiple applications.
This KEMET reed switch is manufactured in Japan and is suitable for industrial, laboratory, electronic manufacturing, HVAC, power monitoring, and other electrical switching needs. Browse more in the EnvMart Reed Switch category for compatible components and solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum switching current of this reed switch is 100 mA.
It operates over a temperature range from -20°C to 150°C.
The maximum switching voltage for this reed switch is 30 V dc.
This model is designed for through hole mounting with wire terminals.
The contacts are made from nickel iron alloy, providing reliable electrical performance.
The dimensions are 6.7 mm in length, 5 mm in width, and 19.1 mm in depth.
It is part of the OHD Thermal Guard series, which includes thermal problem countermeasures.
This reed switch is suitable for atmospheric temperature detection and monitoring overheating in various electronic devices.
The contact resistance is 300 mΩ.
Yes, this reed switch is RoHS compliant, ensuring it meets environmental standards.
The maximum switching power for this reed switch is 1 W.
This reed switch is manufactured in Japan.
