KEMET SPST Through Hole Reed Switch 100 mA 30 V dc OHD5R-30B
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | KEMET |
| Length | 6.7mm |
| Model | OHD5R-30B |
| Depth | 19.1mm |
| Width | 5mm |
| Mount Type | Through Hole |
| Contact Material | Nickel Iron Alloy |
| Series | OHD Thermal Guard |
| Maximum Switching Current | 100mA |
| Maximum Operating Temperature | 150°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -20°C |
| Terminal type | Wire |
| Contact Resistance | 300mΩ |
| Maximum Switching Power | 1W |
| Standards/Approvals | RoHS |
| Maximum Switching Voltage | 30V dc |
Key Features
- Features a SPST (Single Pole Single Throw) contact configuration.
- Maximum switching power is 1 W ensuring efficient operation.
- Nickel Iron Alloy contact material offers durability and corrosion resistance.
- Supports through hole mounting for easy PCB integration.
- Operates reliably within a wide temperature range from -20°C to 150°C.
- Compact size with dimensions 5 mm width, 6.7 mm length, and 19.1 mm depth.
- RoHS compliant ensuring environmental safety.
- Equipped with wire terminal type for secure electrical connections.
Product Description
KEMET OHD5R-30B SPST Through Hole Reed Switch is engineered for precise switching control in electronic circuits where durability and environmental resistance are critical. It supports a contact current of 100 mA and a maximum switching voltage of 30 V dc, making it suitable for various low-power switching applications.
This model’s contact material consists of a Nickel Iron Alloy that enhances reliability and reduces contact resistance to 300 mΩ. The terminal is wire-type, and mounting is through hole, facilitating integration on printed circuit boards.
The device offers excellent operational stability across a wide temperature range of -20°C up to 150°C, which makes it suitable for demanding environments in industrial, laboratory, and automation systems.
Single Pole Single Throw (SPST) contact configuration. Maximum switching power rating of 1 watt. Compact dimensions: 5 mm width, 6.7 mm length, and 19.1 mm depth. RoHS compliant for environmental safety and regulatory compliance.
OHD Thermal Guard series designed for thermal sensing and protection applications. Wire terminal type for reliable and easy electrical connections. High operational life and excellent environmental durability. Made in Japan with high manufacturing standards.
This Reed Switch is ideal for use in applications such as power transistor overheating monitoring, power modules, room heaters, motor control systems, and various electronic appliances that require dependable Reed Switch performance.
Explore a wide range of electronic switching solutions in our catalog to match all your industrial and automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum switching current for this model is 100 mA.
This reed switch operates reliably within a maximum temperature of 150°C.
It features a Single Pole Single Throw (SPST) contact configuration.
The maximum switching voltage is 30 V dc.
The dimensions are 5 mm in width, 6.7 mm in length, and 19.1 mm in depth.
The contact material is Nickel Iron Alloy, which enhances reliability and reduces contact resistance.
The contact resistance is rated at 300 mΩ.
It supports through hole mounting, making it easy to integrate into printed circuit boards.
Yes, it is RoHS compliant, ensuring environmental safety and regulatory compliance.
The minimum operating temperature is -20°C.
It is equipped with a wire terminal type for secure electrical connections.
It is suitable for applications such as power transistor overheating monitoring, motor control systems, and various electronic appliances.
