ABB Miniature Circuit Breaker, 1-Pole, 32A, Type C, 230V AC, 4.5 kA Breaking Capacity 2CSS245202R0324
Specifications
| Country of Origin | India |
|---|---|
| Range | SN201S L |
| Brand | ABB |
| Height | 85mm |
| Model | 2CSS245202R0324 |
| Depth | 85mm |
| IP Rating | IP20 |
| Width | 18mm |
| Mount Type | DIN Rail |
| Current Rating | 32A |
| Series | SN201 |
| Terminal type | Screwless |
| Breaking Capacity | 4.5kA |
| Number of Poles | 1 |
| Standards/Approvals | IEC/EN 60898-1 |
| Rated AC Voltage | 230V ac |
| Tripping Characteristics | Type C |
| Reset Actuator Type | Toggle Switch |
Key Features
- Enables quick and secure installation with screwless terminals.
- Suitable for inductive loads due to Type C tripping characteristic.
- Supports 230V AC rated voltage and 4.5 kA breaking capacity.
- Compact dimensions (18mm width) optimize panel space efficiency.
- Mounts easily on DIN rails with toggle switch actuator for reset.
- IP20 rated for protection against solid objects larger than 12 mm.
- Meets IEC/EN 60898-1 standards for safety and performance.
Product Description
ABB 2CSS245202R0324 Miniature Circuit Breaker (MCB) is engineered for dependable electrical circuit protection in residential and commercial settings. It features a rated current of 32 amperes and a Type C tripping curve, making it ideal for inductive loads such as motors and transformers.
This MCB is rated for 230V AC operation and offers a breaking capacity of 4.5 kA, ensuring safe interruption of high fault currents. The compact 18 mm wide design allows efficient use of space on DIN rail panel installations. Screwless terminal technology facilitates fast, tool-free wiring, enhancing installation efficiency and reducing maintenance risk.
With a toggle switch actuator type, the breaker can be easily reset after tripping incidents. The product complies with IEC/EN 60898-1 standards, confirming its suitability for standard electrical protection requirements. Its IP20 rating provides protection against contact with solid objects above 12 mm, supporting safety during operation.
Typical applications include use in home electrical panels, automation control systems, energy distribution boards, and machinery protection. The breaker is suitable for indoor use and must be installed within appropriate enclosures if deployed in challenging environments.
Enables quick and secure installation with screwless terminals. Suitable for inductive loads due to Type C tripping characteristic. Supports 230V AC rated voltage and 4.5 kA breaking capacity. Compact dimensions (18mm width) optimize panel space efficiency.
Mounts easily on DIN rails with toggle switch actuator for reset. IP20 rated for protection against solid objects larger than 12 mm. Meets IEC/EN 60898-1 standards for safety and performance. Explore more products in the Miniature Circuit Breaker category to find solutions suited for various electrical protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating of this miniature circuit breaker is 32A.
It has a breaking capacity of 4.5 kA, ensuring safe interruption of high fault currents.
This circuit breaker features a Type C tripping characteristic, making it suitable for inductive loads such as motors and transformers.
The rated voltage for this model is 230V AC.
The dimensions are 85mm in height, 85mm in depth, and 18mm in width.
It mounts easily on DIN rails, facilitating straightforward installation.
This circuit breaker has an IP20 rating, providing protection against contact with solid objects larger than 12 mm.
It utilizes screwless terminals, allowing for fast and tool-free wiring.
It complies with IEC/EN 60898-1 standards for safety and performance.
The reset actuator type is a toggle switch, which allows for easy resetting after tripping.
Typical applications include home electrical panels, automation control systems, energy distribution boards, and machinery protection.
This model belongs to the SN201 series.
