ABB Miniature Circuit Breaker 2-Pole 16A Type C 400V AC 6 kA Breaking Capacity 2CDS242701R0164

ABB 2CDS242701R0164 Miniature Circuit Breaker (MCB) is a 2-pole device specifically engineered to provide reliable overcurrent protection in electrical systems operating up to 400 volts AC. Featuring a 16 ampere rated current and a Type C tripping characteristic, this MCB effectively protects circuits against moderate inrush currents such as those generated by motors and transformers, ensuring safety without nuisance tripping during normal operation.

This breaker supports a breaking capacity of 6 kiloamperes, which enables it to safely interrupt high fault currents without damage, enhancing the resilience of your electrical installations. Designed within the System Pro M Compact range, the unit includes screw-type terminals facilitating secure wiring and easy installation on standard DIN rails.

The compact dimensions of 88mm height, 69mm width, and 88mm depth allow for space-efficient integration into control panels and switchboards. Its robust thermomagnetic and electromagnetic tripping mechanisms contribute to accurate and dependable disconnection during overcurrent events. The breaker complies with IEC/EN 60898-1 international standards and offers IP20 and IP40 ingress protection, providing resistance against solid objects and limited moisture ingress to suit various environments.

Manufactured in Germany, this MCB is well-suited for applications across industrial, commercial, and residential settings as part of comprehensive electrical protection schemes. Typical uses include safeguarding circuits for machinery, automation systems, and general-purpose power circuits where reliable fault isolation and minimal downtime are critical.

Equipped with Type C tripping characteristic suitable for devices with moderate startup currents. Current rating of 16 A for versatile protection capacity. Compatible with screw terminals for secure electrical connections.

6 kA breaking capacity for safe fault current interruption. Marked by compliance with IEC/EN 60898-1 standards. Compact size with DIN rail mounting for easy installation. Durable design ensures endurance for up to 20,000 operational cycles.

IP20, IP40 protection rating for ingress resistance. Thermomagnetic and electromagnetic trip mechanisms for reliable circuit interruption. Made in Germany meeting stringent quality controls. For additional information and related products, explore the MCB category on EnvMart to find suitable accessories and complementary circuit protection devices.
