Microchip Split Gate 8 MB Serial-SPI Flash Memory 8-Pin SOIC SST25VF080B-50-4I-S2AE

Microchip SST25VF080B-50-4I-S2AE is an 8 MB serial flash memory device using high-performance CMOS SuperFlash technology with Split Gate cell architecture. It is housed in an 8-pin SOIC surface mount package measuring 5 mm length, 4 mm width, and 1.5 mm height.

This flash memory supports a Serial Peripheral Interface (SPI) operating up to 50 MHz clock frequency, providing synchronous data access suitable for embedded industrial applications. The device operates on a supply voltage range of 2.7 to 3.6 volts, optimizing low power consumption with a typical supply current of 15 mA.

The Split Gate cell design enhances reliability and manufacturability, delivering superior endurance and endurance characteristics. Operating temperatures from -40°C to +85°C ensure functionality across harsh industrial and commercial environments. The memory organization is 8 megabits with 8 bits per word, and it features software-controlled write protection and hardware hold functions for secure memory management.

The SST25VF080B series provides low power operation with features like busy status read out and end-of-write detection, simplifying software control. It is widely used in industrial, consumer electronics, and communication equipment requiring reliable non-volatile memory storage.

Memory Size: 8 MB with 8 bits per word organization. Serial SPI supporting 50 MHz clock frequency. Package: 8-pin SOIC surface mount with compact dimensions. Operating Voltage: 2.7 V to 3.6 V single supply. Operating Temperature: -40°C to 85°C industrial grade.

Low operating current at 15 mA for energy-efficient use. Supports software polling and write protection features.

This Microchip Flash Memory component is ideal for embedded systems, industrial automation, consumer electronics, and communications applications requiring robust, reliable, and compact data storage solutions. Explore more flash memories and semiconductor products at EnvMart.
