XP Power DC/DC Switching Regulator Through Hole 12V DC Output Voltage 72V DC Input Voltage 500mA Output Current SRH05S12

XP Power SRH05S12 is a high-performance DC/DC switching regulator designed for electronic and industrial applications requiring stable voltage regulation. Featuring through-hole mount capability and a compact SIP package, it provides a reliable 12V DC output at up to 500mA output current, drawing from a wide input voltage range of 17V to 72V DC. This regulator operates efficiently at 94% and maintains a low ripple and noise profile of 75mV peak-to-peak, making it suitable for sensitive electronics.

Designed to withstand harsh environments, the SRH05S12 supports operation in temperature ranges from -40°C to +85°C, ensuring robustness in industrial and commercial setups. Its line regulation at 0.01% and load regulation at 0.006% guarantee precise voltage control even under fluctuating input and load conditions. The 3-pin SIP package provides easy insertion and soldering for PCB assemblies.

The switching frequency range coupled with a compact footprint of 11.68mm length, 10.16mm width, and 7.5mm depth enables integration into dense electronic assemblies. With an MTBF exceeding 4.5 million hours, the SRH05S12 offers excellent long-term reliability for continuous duty applications.

Compliant with standards including EN 61000 series and MIL-HDBK-217F, this switching regulator suits applications in industrial automation, power supply design, telecommunications equipment, and embedded systems requiring dependable voltage conversion with minimal heat generation.

High efficiency of 94% reduces power loss during operation. Wide input voltage range from 17V to 72V DC accommodates various applications. Operates reliably in extreme temperatures from -40°C to +85°C. Low ripple and noise of 75mV peak-to-peak ensures clean power output.

Compact SIP package with 3 pins suitable for through-hole PCB integration. Excellent line regulation of 0.01% and load regulation of 0.006% for stable voltage supply. Dimensions: Length 11.68mm, Width 10.16mm, Depth 7.5mm for compact installation.

Mean Time Between Failures (MTBF) exceeds 4.5 million hours for high reliability.

This product is ideal for industrial and laboratory power conversion needs, including use in manufacturing, automation, telecommunications, and control systems. Explore more power management and voltage converting solutions in the Electronics & Electricals category on EnvMart.
