APEM IP Series Momentary Push Button Switch, Panel Mount, 12 mm Cutout, SPST, IP67, Orange Dome Actuator, 48V AC IPC3FAD9

APEM IPC3FAD9 is a momentary, panel-mount push button switch from the IP Series designed for demanding industrial and automation applications. The switch features a 12 mm panel cutout and a single pole single throw (SPST) contact configuration, making it suitable for on/off switching tasks in control panels and machinery.

The robust construction includes an orange dome actuator that offers excellent tactile feel and ease of operation. The non-illuminated actuator ensures a simple yet effective control element. The device is rated IP67, providing complete dust ingress protection and water immersion resistance, making it ideal for harsh environments including outdoor and industrial settings subjected to salt spray and moisture.

This switch supports a maximum AC contact voltage of 48 V and a current rating of 5 amperes, making it capable of handling moderate power loads in electrical control circuits. The terminal type is through hole with 500 mm wire lead terminals for straightforward wiring and installation into panels.

The operating temperature ranges from -40°C to 85°C, enabling reliable performance in extreme temperature conditions. The construction complies with RoHS directives and meets standards EN 50102, IEC 512-4, and IEC 512-6. The switch is very robust with IK06 impact resistance, ensuring mechanical durability.

Ideal for use in industrial automation, electrical switch panels, machinery control systems, and other commercial electrical applications requiring a reliable, sealed momentary push button switch. The product originates from France, highlighting quality manufacturing standards.

The switch is momentary and provides excellent tactile feedback. It is constructed to be highly robust with IK06 impact protection. The panel mount design includes a 12 mm cutout for easy integration. The device is sealed to IP67, ensuring dust-tight and immersion protection.

Terminals use through-hole mounting with 500 mm wire leads for convenient connection. Operating temperature ranges from -40°C to 85°C, suitable for extreme conditions. Switch contact current rating is 5 A AC, supporting moderate electrical loads.

The actuator is an orange colored dome style with a non-illuminated design. Manufactured in France with RoHS compliance and relevant standards EN 50102, IEC 512-4, IEC 512-6. Explore more push button switches and related components from APEM and other leading brands at EnvMart for industrial, automation, and electrical applications.
