Wurth Elektronik WR-MJ Series RJ45 Connector Female, PCB Mount, Cat3 Nickel Plated Bronze Shield Horizontal 8 Port 8 Way RJ45

Wurth Elektronik RJ45 connector RJ45 female PCB mount model RJ45, Cat3 category, nickel plated bronze shield, horizontal orientation with 8 ports and 8 ways is designed for reliable Ethernet connectivity in electronic applications.

This modular jack connector supports through-hole technology (THT) mounting on printed circuit boards, offering a sturdy and durable solution ideal for telecommunications and networking setups requiring Cat3 performance. The contact material is a copper alloy plated with gold to ensure optimal electrical conductivity and corrosion resistance over time.

Engineered to operate efficiently under temperatures ranging from -40°C to +85°C, it is suitable for industrial and commercial environments which experience diverse temperature conditions. The solder termination type ensures secure joints on PCB for enhanced mechanical stability.

Physical measurements of this connector are carefully optimized to fit into compact network devices: length of 59.2 mm, width 25.3 mm, and depth 28.2 mm, with a horizontal tab up and down design and 8P8C number of pins. The shield provides effective EMI protection thanks to the nickel-plated bronze construction, enhancing signal integrity and minimizing interference in network communications.

The WR-MJ series maintains a high standard of quality with a lifecycle rated for 500 mating cycles, making it suitable for applications where repeated plugging and unplugging occurs.

Typical industrial uses include integration into electronic networking hardware, telecommunications infrastructure, data communication devices, and various control systems requiring Ethernet connectivity, especially in PCB assembly contexts.

The connector is a modular jack designed for PCB mounting and supports horizontal orientation. Compatible for Cat3 LAN category with 8-way and 8-port configuration. Features a gold-plated copper alloy contact material ensuring reliable electrical connections.

Engineered for operating temperatures ranging from -40°C to 85°C. Termination is via solder for secure installation on printed circuit boards. The series designation is WR-MJ, ensuring consistent performance and interchangeability.

Physical dimensions include length of 59.2 mm, width of 25.3 mm, and depth of 28.2 mm. Designed for 500 mating cycles, providing durable connector lifespan. Shielding includes nickel plated bronze to reduce EMI and ensure signal integrity.
