Phoenix Contact KDS10 Series Straight PCB Terminal Block, 1 Contact, 10 mm Pitch, 320 V, 76 A Current, 1 Row KDS10
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 320V |
| Brand | Phoenix Contact |
| Orientation | Straight |
| Current | 76A |
| Model | KDS10 |
| Housing Material | Polyamide |
| Series | KDS10 |
| Number of Rows | 1 |
| Pitch | 10mm |
| Number of Contacts | 1 |
Key Features
- Single contact design with a 10 mm pitch for precise PCB spacing.
- Rated for a high current carrying capacity of 76 A at 320 V.
- Constructed from durable polyamide housing ensuring chemical and temperature resistance.
- Screw connection technology provides secure conductor retention without need for re-tightening.
- Side-stackable units allow flexible extension and efficient circuit board packing.
- Through-hole mounting ensures strong mechanical and electrical integrity with wave soldering compatibility.
- Compact 1-row architecture facilitates easy installation and maintenance in electronic assemblies.
- Ideal for industrial, laboratory, and manufacturing applications requiring robust PCB connector solutions.
Product Description
Phoenix Contact KDS10 Series straight PCB terminal block offers a high-performance solution for connecting electrical conductors to printed circuit boards in a compact form factor. This modular feed-through terminal with a 10 mm pitch supports a single contact and carries currents up to 76 A at 320 V, making it suitable for demanding electronic applications.
The terminal block features durable polyamide housing that provides robust mechanical protection and resistance to temperature extremes from -40°C to 120°C. Its screw connection system secures conductors firmly, preventing loosening and minimizing the risk of wiring faults over time.
The side-stackable design allows multiple units to be locked together creating continuous terminal strips, optimizing PCB space utilization and simplifying wiring layouts. The through-hole mounting is compatible with wave-soldering processes to ensure secure installation with excellent electrical and mechanical performance.
Engineered for industrial, laboratory, HVAC, manufacturing, and commercial electronic assemblies, this terminal block blends reliability with ease of service. Its green polyamide body and compliance with UL and CSA approvals provide confidence in connection quality within various electrical environments.
The product contains 1 contact, 1 row, with dimensions of 36.8 mm length, 10 mm width, and 28.7 mm depth. It is manufactured in Germany ensuring high-quality standards and product consistency.
Single contact with a 10 mm pitch for PCB terminals. Supports up to 76 A current at 320 V voltage rating. Constructed from resilient polyamide housing material. Screw connection with locking mechanism holds conductors firmly.
Side-stackable modular design for flexible terminal strips. Through-hole mounting compatible with wave soldering. Dimensions approximately 36.8 x 10 x 28.7 mm (LxWxD). Suitable for industrial, commercial, and laboratory PCB connections.
Explore the full range of Phoenix Contact PCB Terminal Blocks and connectors at EnvMart for reliable, high-quality electronic component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 76 A and a voltage rating of 320 V.
The terminal block features a pitch of 10 mm, designed for precise PCB spacing.
It is constructed from durable polyamide, providing resistance to chemicals and temperature extremes.
This model has a single contact design, suitable for various applications.
The dimensions are approximately 36.8 mm in length, 10 mm in width, and 28.7 mm in depth.
Yes, the through-hole mounting design is compatible with wave soldering processes.
Yes, the side-stackable design allows for flexible extension and efficient circuit board packing.
It operates effectively within a temperature range of -40°C to 120°C.
The KDS10 series terminal block is manufactured in Germany, ensuring high-quality standards.
It is designed for use in industrial, laboratory, HVAC, manufacturing, and commercial electronic assemblies.
This model features a single row configuration, facilitating easy installation and maintenance.
