Telemecanique Sensors Threaded Barrel Inductive Proximity Sensor M30 x 1.5 NPN OsiSense XS 48V dc 22 mm XS230AANAM12

Telemecanique Sensors XS230AANAM12 is a threaded barrel Inductive Proximity Sensor designed for reliable, non-contact detection of metal objects up to 22 mm distance. Incorporating the OsiSense XS series technology, this sensor operates at a maximum supply voltage of 48 V dc and provides NPN output for seamless integration with industrial control systems.

The sensor features a robust polyphenylene sulphide housing with M30 x 1.5 thread size and has dimensions of 70 mm length, 36 mm width, and 36 mm depth, making it ideal for tight installation areas. It is non-flush mountable and equipped with an M12 connector for secure and quick electrical connection.

Certified with CCC, CE, CSA, and UL standards, this IP69K rated sensor ensures resistance against dust, water jets, and harsh cleaning processes, suitable for food, beverage, pharmaceutical, and general industrial applications.

Its operating temperature range of -25°C to +85°C allows use in freezing and sterilization conditions. The sensor supports a maximum switching frequency of 500 Hz and switching current of 200 mA, providing quick and reliable detection performance.

Applications include metal detection in food processing, pharmaceutical manufacturing, and other industrial environments requiring high detection accuracy and reliability. Its unshielded design specializes in detecting only metal objects, unaffected by dirt, oils or surface finish.

Equipped with M30 x 1.5 threaded barrel for easy mounting. Polyphenylene sulphide housing provides chemical and mechanical durability. IP69K rating ensures protection in harsh washdown environments. Operating temperature from -25°C to +85°C for versatile industrial use.

High switching frequency of 500 Hz enables fast operation. Non-flush mount type with unshielded sensing for metal object detection. M12 connector terminal facilitates quick assembly and replacement. Complies with international safety and quality standards CCC, CE, CSA, and UL.

NPN output type compatible with numerous PLCs and control systems. Ideal for food, beverage, pharmaceutical, and general industry applications. Explore EnvMart’s extensive catalogue of sensors and industrial controls for advanced automation and detection solutions to fit your application.
