HARTING Stamped 15 Way Straight 2.77 mm Pitch Panel Mount D-Sub Connector with Flange Female 09672154704

Free Delivery in India | Lowest Global Shipping Charges

HARTING Stamped 15 Way Straight 2.77 mm Pitch Panel Mount D-Sub Connector with Flange Female 09672154704

Name: HARTING Stamped 15 Way Straight 2.77 mm Pitch Panel Mount D-Sub Connector with Flange Female 09672154704
Brand: HARTING
SKU: 146190
Price: 5.54 USD
Availability: InStock



Category D-Sub Connector Brand HARTING Condition New

Specifications

Country of Origin	China
Voltage	1kV
Brand	HARTING
Orientation	Straight
Current	6.5A
Mount Type	Panel Mount
Housing Material	Fibreglass Reinforced Thermoplastic
Contact Material	Copper Alloy
Series	Stamped
Mounting Hardware	Flange
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Pitch	2.77mm
Standards/Approvals	UL Recognised, UL 94-V0, RoHS
Contact Plating	Steel
Number of Contacts	15
Contact Gender	Female
Connector Gender	Female
Connector Type D	D-Sub

Key Features

The connector features 15 contacts ensuring stable multi-connection capability.
Designed with a robust fibreglass reinforced thermoplastic housing for durability.
Supports a current rating of 6.5 amperes for medium power uses.
Includes a flange mounting hardware for secure panel installation.
Operates reliably within temperature range of -40°C to 85°C.
Connector gender and contact gender are both female for compatibility with male plugs.
Offers solder termination type with straight stamped contacts for ease of assembly.
Rated for a voltage of 1 kV, ensuring insulation safety.

Product Description

HARTING 09672154704 is a stamped 15 way straight panel mount D-Sub connector with a 2.77 mm pitch designed for robust and reliable electrical connections in industrial, laboratory, manufacturing, and commercial electronic equipment.

This female connector features a fibreglass reinforced thermoplastic housing and flange mounting hardware for secure panel installation. Its copper alloy contacts with steel plating provide excellent conductivity and corrosion resistance.

Rated to carry a current of 6.5A at a voltage of 1 kV, this connector operates effectively in environments ranging from -40°C to a maximum of 85°C, and is certified UL Recognised, UL 94-V0, and RoHS compliant, ensuring safety and environmental standards are met.

The solder cup termination with straight stamped contacts allows for reliable soldering and assembly in electronics manufacturing. Its 15 contacts offer versatile multi-connection support for complex electrical assemblies.

The connector features 15 contacts ensuring stable multi-connection capability. Designed with a robust fibreglass reinforced thermoplastic housing for durability. Supports a current rating of 6.5 amperes for medium power uses.

Includes a flange mounting hardware for secure panel installation. Operates reliably within temperature range of -40°C to 85°C. Connector gender and contact gender are both female for compatibility with male plugs. Offers solder termination type with straight stamped contacts for ease of assembly.

Rated for a voltage of 1 kV, ensuring insulation safety. Complies with UL Recognised, UL 94-V0, and RoHS standards. Contact material is copper alloy with steel plating to resist corrosion. Country of origin is China.

This D-Sub Connector is suitable for demanding industrial, manufacturing, water treatment, and electronic applications requiring secure and efficient panel-mount connections. It meets high safety and environmental standards to support reliable system operation.

Explore more high-quality electronic connectors and components at EnvMart for your professional and industrial needs.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model supports a current rating of 6.5 amperes, making it suitable for medium power applications.

It is rated for a voltage of 1 kV, ensuring insulation safety for various applications.

This connector operates reliably within a temperature range of -40°C to 85°C.

It features a flange mount type for secure panel installation.

This model has 15 contacts, providing stable multi-connection capability.

The housing is made from fibreglass reinforced thermoplastic, and the contacts are copper alloy with steel plating for corrosion resistance.

It offers a solder termination type with straight stamped contacts for ease of assembly.

Yes, it is certified UL Recognised, UL 94-V0, and RoHS compliant, meeting high safety and environmental standards.

The pitch size for this connector is 2.77 mm.

Both the connector gender and contact gender are female, allowing compatibility with male plugs.

The country of origin for this model is China.

This D-Sub connector is suitable for industrial, manufacturing, water treatment, and electronic applications requiring secure panel-mount connections.
