Theben Digital DIN Rail Time Switch 24V Single Channel SPDT Astronomical Weekly Program TR610
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | Theben |
| Battery Life | 10year |
| Height | 90.1mm |
| Model | TR610 |
| Depth | 69.2mm |
| Series | TR610 Top |
| Contact Configuration | SPDT |
| Sub Type | Digital |
| Terminal type | DuoFix Spring |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS, VDE, EN 60 730-1 |
| Maximum Supply Voltage | 24V |
| Units Measured | Days, Hours, Minutes, Seconds |
| Memory Spaces | 56 |
| Segment Length | 1min |
Key Features
- The device features 56 memory locations for flexible scheduling.
- DuoFix spring terminals support wire diameters from 0.5 mm² to 2.5 mm².
- Zero-cross switching ensures relay-saving operation and supports high lamp loads.
- Automatic summer and winter time changeover enhances convenience.
- Controls with text-oriented user guidance and PIN coding for security.
- Operates fully without mains connection during programming.
- Shortest switching time is 1 minute for precise control intervals.
- Wide ambient temperature range from -30 °C to 55 °C for varied environments.
Product Description
Theben TR610 Digital DIN Rail Time Switch is a single channel, single pole double throw (SPDT) astronomical time switch designed for industrial and automation control systems. Operating on 24V supply voltage, it provides accurate timing with a weekly program and 56 memory spaces, suitable for controlling lighting and industrial equipment schedules. The compact design includes a highly temperature-resistant, self-extinguishing thermoplastic housing conforming to RoHS, VDE, and EN 60 730-1 standards. Its DuoFix spring terminals support wire diameters from 0.5mm² to 2.5mm² including wire end sleeves, enabling secure and easy wiring installation.
The device includes advanced features such as zero-cross switching for relay-saving operation and high lamp load capability. It offers automatic switching between summer and winter time, pre-set date and time, PIN code protection for program security, and a holiday program function for extended control periods. The user interface features text-oriented guidance on an illuminated display that can be switched off. Programming and operation can be performed without mains power, enhancing safety during setup.
The TR610 supports switching intervals as short as one minute, providing fine control over timing sequences. It is rated for operating ambient temperatures from -30 °C up to 55 °C, making it adaptable to various industrial, commercial, and HVAC environments. This digital time switch can be integrated with Bluetooth low energy OBELISK top3 modules for wireless configuration. It is ideal for use in manufacturing automation, building management, power distribution control, and general industrial process timing applications.
The device offers 56 memory spaces for complex timing needs. DuoFix spring terminal connections enable robust wiring. Zero-cross switching reduces relay wear and extends device life. Pre-programmed automatic daylight saving adjustments.
PIN coding and holiday programs provide enhanced security and scheduling. It caters to automation and control requirements in electrical and industrial systems. Explore more electronic automation controls and Time Switches in EnvMart’s dedicated Industrial Automation Systems category for reliable timing solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum supply voltage for this model is 24V.
It features 56 memory locations for flexible scheduling.
The shortest switching time is 1 minute, allowing for precise control intervals.
This model has a single pole double throw (SPDT) contact configuration.
The dimensions are 90.1mm in height and 69.2mm in depth.
It uses DuoFix spring terminals that support wire diameters from 0.5 mm² to 2.5 mm².
It conforms to RoHS, VDE, and EN 60 730-1 standards.
The operating ambient temperature range is from -30 °C to 55 °C.
Yes, it includes automatic switching between summer and winter time.
Yes, it can operate fully without mains connection during programming.
The battery life is rated at 10 years.
It is suitable for manufacturing automation, building management, power distribution control, and general industrial process timing applications.
