ABB Residual Current Circuit Breaker with Overload Protection 40A 1-Pole 30mA Trip 2CSR275151R1404 DSE201 M C40 A30 - N Blue
Specifications
| Country of Origin | India |
|---|---|
| Range | System Pro M Compact |
| Brand | ABB |
| Height | 88mm |
| Model | 2CSR275151R1404 DSE201 M C40 A30 - N Blue |
| Depth | 143mm |
| Width | 36mm |
| Mount Type | DIN Rail |
| Current Rating | 40A |
| Series | DSE201 M |
| Terminal type | Screw |
| Breaking Capacity | 10kA |
| Number of Poles | 1 |
| Standards/Approvals | RoHS, IEC |
| Rated AC Voltage | 240V ac |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Trip Sensitivity | 30mA |
| Earth Leakage Protection Type | Type A |
| RCBO's | DIN rail mounting with an operating temperature range of -25 to +55 °C. Optimum frequency range of 50 to 60Hz |
Key Features
- This circuit breaker provides combined protection against short circuits, overloads, and earth leakages.
- It mounts easily on DIN rails and operates within a temperature range of -25 to +55 °C.
- The device has a breaking capacity of 10kA and is suitable for 240V AC systems.
- Equipped with screw terminals and a toggle switch reset actuator for user-friendly operation.
- Designed according to IEC standards and compliant with RoHS for safety and reliability.
- The compact size dimensions are 88mm height, 143mm depth, and 36mm width.
- Provides Type A earth leakage protection through thermal magnetic tripping mechanism.
- Ideal for residential, commercial, and industrial electrical safety enhancement.
Product Description
ABB 2CSR275151R1404 DSE201 M C40 A30 - N Blue Residual Current Circuit Breaker with Overload Protection offers advanced 1-pole protection integrating residual current detection and overload protection in a single compact module designed for DIN rail mounting. This device ensures comprehensive electrical circuit safety by preventing damage from overload currents, short circuits, and earth faults.
With a rated current of 40A and a trip sensitivity of 30mA, it quickly responds to hazardous leakage currents to protect users and equipment. The circuit breaker features a Type C tripping characteristic with thermal magnetic mechanism, making it suitable for most residential and commercial electrical systems.
The rated voltage is 240V AC and the unit has a breaking capacity of 10kA, ensuring reliable interruption under fault conditions. Installation is simplified by screw terminals and a toggle switch for manual reset. The device is engineered to operate in ambient temperatures ranging from -25 to +55 degrees Celsius and supports optimal frequencies of 50 to 60Hz.
The compact physical dimensions of 88mm height, 143mm depth, and 36mm width minimize panel space usage. Conformance to IEC standards and RoHS compliance underscores the product's safety and environmental considerations.
Combined residual current and overload protection in one compact unit. 40A current rating with 30mA earth leakage sensitivity for safety. Thermal magnetic trip mechanism with Type C characteristics. DIN rail mounting and screw terminal connections for easy installation.
Operating temperature range -25°C to +55°C suitable for diverse environments. Breaking capacity of 10kA ensures fault interruption reliability. Compact dimensions save panel space without compromising protection. RoHS and IEC compliant ensuring quality and environmental standards.
This residual current breaker is ideal for residential, commercial, industrial electrical installations where precise and reliable earth fault and overload safety control is critical. It helps in preventing fire hazards and electrical shock risks by detecting earth leakage currents promptly and tripping the circuit reliably.
For more electrical protection devices and related equipment, browse the Circuit Breakers & Fuse category on EnvMart to find suitable components matching your application needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The circuit breaker has a current rating of 40A.
It features a trip sensitivity of 30mA for earth leakage protection.
The breaking capacity is 10kA, ensuring reliable interruption under fault conditions.
This model utilizes a thermal magnetic tripping mechanism with Type C characteristics.
The dimensions are 88mm in height, 143mm in depth, and 36mm in width.
It is rated for 240V AC systems.
The operating temperature range is from -25°C to +55°C.
It mounts easily on DIN rails, simplifying installation.
It features screw terminals for connections.
Yes, it is compliant with RoHS and IEC standards.
This model provides Type A earth leakage protection.
It is suitable for residential, commercial, and industrial electrical installations.
