ABB Residual Current Circuit Breaker with Overload Protection 40A 2-Pole 230V AC 30mA Trip Sensitivity Type 2CSR252001R1405

Free Delivery in India | Lowest Global Shipping Charges

ABB Residual Current Circuit Breaker with Overload Protection 40A 2-Pole 230V AC 30mA Trip Sensitivity Type 2CSR252001R1405



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	DS200
Brand	ABB
Height	93mm
Model	2CSR252001R1405
Depth	69mm
Width	70mm
Mount Type	DIN Rail
Standards	IEC/EN 60947-2
Current Rating	40A
Series	DS200
Terminal type	Busbar Terminal
Breaking Capacity	10kA
Number of Poles	2
Standards/Approvals	IEC/EN 60947-2, IEC/EN 61009-1
Rated AC Voltage	230V ac
Tripping Characteristics	Type B
Tripping Mechanism	Thermal Magnetic
Trip Sensitivity	30mA
Operating Characteristic	Instantaneous

Key Features

Combines overload and short-circuit current protection with earth fault detection.
Equipped with instantaneous tripping characteristic Type B for precise protection.
Features a 2-pole design with thermal magnetic tripping mechanism.
Mounts easily on DIN rails with busbar terminal type connections.
Meets IEC/EN 60947-2 and IEC/EN 61009-1 international safety standards.
Offers a breaking capacity of 10kA ensuring robust circuit breaking capability.
Designed and manufactured in Italy to exacting quality standards.

Product Description

ABB 2CSR252001R1405 Residual Current Circuit Breaker with Overload Protection is engineered to provide comprehensive electrical protection by combining overload, short-circuit, and residual current breaking functionalities. Rated for 40A current and operating at 230V AC, this 2-pole device offers a trip sensitivity of 30 mA, ensuring sensitive earth fault detection to protect people and equipment.

The breaker employs a thermal magnetic tripping mechanism with an instantaneous tripping characteristic of Type B, optimized for AC type residual currents. This enables precise and reliable interruption of fault currents to prevent damage and hazards. The compact design allows easy installation on standard DIN rails and uses busbar terminals for secure electrical connections.

With dimensions of 93mm height, 70mm width, and 69mm depth, the DS200 series breaker fits into electrical panels efficiently without occupying excessive space. It has a breaking capacity of 10kA, supporting high fault current interruption capabilities suitable for a variety of electrical installations.

Certified under IEC/EN 60947-2 and IEC/EN 61009-1, this breaker meets stringent international safety and performance standards. Manufactured in Italy, the product upholds ABB's reputation for superior quality and reliability in electrical protection devices.

Combines overload, short-circuit, and earth fault current protection. Instantaneous Type B tripping for sensitive, fast response. Thermal magnetic tripping mechanism for dependable operation. DIN rail mounting with busbar terminal connection.

Compact form factor designed for space-saving panel installations. Breaking capacity of 10kA for robust fault current interruption. Certified to IEC/EN standards ensuring global safety compliance.

This ABB 2CSR252001R1405 circuit breaker is ideal for industrial, commercial, and residential electrical safety applications requiring advanced protection against multiple electrical faults. Explore our full range of circuit breakers and electrical protection devices to find the perfect fit for your project or maintenance needs at EnvMart.
