DFRobot Single Board Computer Intel Atom X5-Z8300 2GB DDR3L RAM 32GB eMMC Windows 10 Home Edition DFR0418

DFRobot DFR0418 Single Board Computer features the powerful Intel Atom X5-Z8300 processor with a clock speed of 1.8GHz, integrated with 2GB DDR3L RAM and 32GB eMMC Flash memory. This compact and versatile SBC measures 88 x 70 mm and runs the full Windows 10 Home Edition operating system, providing a complete PC experience in a small form factor.

Connectivity is comprehensive, offering USB 3.0 and USB 2.0 ports, WiFi 802.11n wireless networking, Bluetooth 4.0, 100Mbps Ethernet LAN, HDMI output, and MIPI-DSI for display interfaces. The board also includes an Arduino Leonardo ATmega32U4 co-processor, allowing it to serve as an embedded controller for sensor inputs, motor control, and relay operations, programmable like an Arduino Leonardo.

A micro SD card slot is available for additional storage expansion. The board provides GPIO ports with 6 pins accessible to the Intel processor and 20 pins managed by the ATmega co-processor. Other hardware features include six Gravity Interface connectors and an onboard touch panel connector.

This Single Board Computer is suitable for a wide variety of industrial, laboratory, embedded systems, development, and STEM education projects. It supports Windows-based software applications and hardware interfacing, making it an excellent tool for prototyping and design testing.

The package includes a WiFi antenna for enabling wireless connectivity. Optional accessories such as a heatsink kit or cooling fan can be added to mitigate thermal throttling under heavy processing loads.

Features an Intel Cherry Trail Z8350 core processor operating at 1.8GHz frequency. Includes 2GB DDR3L RAM and 32GB eMMC Flash memory. Multiple interfaces including USB, WiFi, Bluetooth, Ethernet, HDMI, and MIPI-DSI. Arduino Leonardo ATmega32U4 co-processor for embedded controller functions.

Compact dimensions: 88 mm length x 70 mm height. Expandable storage via micro SD card slot. Pre-installed Windows 10 Home Edition license. GPIO: 6 pins for Intel processor, 20 pins for ATmega processor. Equipped with Gravity Interface connectors and onboard touch panel support.
