Amphenol Industrial SURLOK PLUS RADSOK EV Connector Male 300A SLPPC70BSB1 / C10-730190-1701
Specifications
| Country of Origin | China |
|---|---|
| Brand | Amphenol Industrial |
| Colour | Black |
| Orientation | Right Angle |
| Current | 300A |
| Height | 88.5mm |
| Model | SLPPC70BSB1 / C10-730190-1701 |
| Depth | 40.5mm |
| IP Rating | IP67 |
| Connector Type | RADSOK |
| Width | 30.3mm |
| Mount Type | Cable |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | SURLOK PLUS |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Pin Diameter | 10.3mm |
| Number of Rows | 1 |
| Wire size | 70mm² |
| Operating Voltage | 1000V |
| For Use With | SurLok 1-Position Receptacle |
| Standards/Approvals | UL 94-V0 |
| Number of Contacts | 1 |
| Contact Gender | Female |
| Connector Gender | Male |
| Better World Claim | Renewable Energy Solution |
Key Features
- The connector features a 10.3mm pin diameter and terminates to 70mm² wires with crimp termination.
- It supports an operating voltage of 1000V and a current rating of 300A for heavy-duty applications.
- The connector offers IP67 ingress protection and a UL 94-V0 flammability rating for durability and safety.
- Designed with R4 Radsock technology, it delivers high tensile strength connection and highly conductive surface area.
- The plug rotates 360° and includes a spring locking mechanism with a keyed design to prevent mismating.
- Suitable for Electric Vehicle (EV) systems, rail mass transit, process control, medical, and battery management applications.
- Constructed with a thermoplastic housing and copper alloy contacts to ensure long-lasting performance.
Product Description
Amphenol Industrial SLPPC70BSB1 / C10-730190-1701 SURLOK PLUS RADSOK EV Connector Male 300A is a premium, field-installable EV connector designed for demanding industrial and automotive electrical systems. This connector provides a compact, quick mating compression lug with a press-to-release locking mechanism, ensuring secure and reliable connections.
With an IP67 rating, the connector is robust and environmentally sealed to withstand harsh conditions. The 10.3mm pin diameter plug terminates to 70mm² wires with a crimp termination, suitable for applications requiring high current and voltage endurance up to 300A and 1000V respectively.
Incorporating advanced R4 Radsock technology, it guarantees a high tensile strength connection with an enhanced conductive surface area, optimizing electrical performance. The connector features a 360° rotating plug, a spring locking system, and a keyed design to prevent mismatching of connections, enhancing operational safety and ease of use.
This connector is compliant with UL 94-V0 flammability standards and includes a thermoplastic housing alongside copper alloy contacts for durability and efficiency. Its dimensions stand at 88.5mm in height, 30.3mm in width, and 40.5mm in depth with a right-angle orientation, suiting space-constrained installations.
The Amphenol SURLOK PLUS range finds extensive application in Electric Vehicles (EV/HEV), rail mass transit, process control, medical equipment, and Battery Management Systems (BMS) or energy storage solutions, supporting renewable energy initiatives.
The connector supports heavy equipment, process control, and rail mass transit applications. Ensures a reliable connection with spring locking and keyed design to prevent mismating. Offers comprehensive protection with IP67 ingress and UL 94-V0 flammability rating.
Constructed with durable thermoplastic housing and copper alloy contacts for enhanced performance. Connector rotation capability allows flexibility in installation orientation.
This Amphenol Industrial EV connector delivers trusted performance in industrial and automotive use cases, providing value in high-current, environmentally demanding installations. Explore more products in the EV Connectors category to find optimal solutions for your application needs.
