ABB High Performance S800S Miniature Circuit Breaker, 2-Pole, 63A, Type B Tripping, 690V AC, 250V 2CCS862001R0635 S802S-B63

ABB 2CCS862001R0635 S802S-B63 High Performance S800S Miniature Circuit Breaker is a robust 2-pole electrical protective device, engineered to manage commercial and industrial electrical systems reliably. It supports a current rating of 63A with type B tripping characteristics that activate between 3 to 5 times the rated current to prevent overload and protect connected equipment effectively.

This miniature circuit breaker is rated for a maximum AC voltage of 690V and DC voltage of 250V, designed to deliver a high breaking capacity of 50 kA, ensuring the safe interruption of fault currents to prevent electrical fires and equipment damage.

The device mounts easily on standard DIN rails and features reliable screw terminal connections, making installation and maintenance straightforward. It incorporates both electromagnetic and thermomagnetic tripping mechanisms that provide quick response to short circuits and sustained overload conditions respectively, enhancing overall safety in electrical circuits.

With a compact size of 54mm (width), 95mm (height), and 88.5mm (depth), it fits efficiently into electrical panels and distribution boards. The IP20 rating provides protection against solid foreign objects of 12.5mm and greater, preventing accidental contact with live components.

This circuit breaker complies fully with international standards IEC/EN 60898-1 and IEC/EN 60947-2 and is manufactured in Switzerland, affirming top quality and reliability. Type B tripping characteristics ensure protection against mild overload conditions typical of commercial and industrial equipment.

High breaking capacity of 50kA allows safe disconnection during fault conditions. Compact dimensions optimize panel space usage. Durable screw type terminals guarantee secure electrical connections. DIN rail mount enhances compatibility with standard control panels and switchboards.

Electromagnetic and thermomagnetic trip mechanisms offer comprehensive overload and short circuit protection.

This Miniature Circuit Breaker is ideal for commercial electrical installations, industrial machinery safety, building automation, and distribution panel protection, delivering high reliability and safety for diverse electrical systems.
