Weidmüller Panel Power Relay 24V dc Coil 5A Switching Current 4PDT DRM Series 7760056079
Specifications
| Country of Origin | China |
|---|---|
| Brand | Weidmüller |
| Height | 28mm |
| Length | 21.5mm |
| Width | 36mm |
| Mount Type | Panel |
| Contact Material | Silver Alloy |
| Series | DRM |
| Maximum Operating Temperature | 60°C |
| Contact Configuration | 4PDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 5A |
| Terminal type | Plug-In |
| Contact Resistance | 50mΩ |
| Standards/Approvals | EAC, RoHS |
| Coil Resistance | 630Ω |
| Coil Voltage | 24V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 0.9W |
Key Features
- The relay has a coil voltage of 24V dc ensuring efficient actuation.
- It features a robust silver alloy contact material for reliable conductivity.
- The device supports a switching AC voltage up to 250V ac.
- Designed with a compact panel mount configuration and plug-in terminals.
- The coil resistance is 630 ohms with a coil power consumption of 0.9W.
- Operational temperature range is from -40°C to a maximum of 60°C for versatile industrial environments.
- Contact resistance is low at 50 milliohms, minimizing power loss.
- Part of the DRM series known for longer service life and minimized contact wear.
Product Description
Weidmüller 7760056079 Panel Power Relay is a high-quality power relay designed specifically for panel installation in industrial and commercial electrical systems. It features a 24V dc coil voltage and supports a switching current of 5A with a 4PDT (Four Pole Double Throw) contact configuration, making it suitable for applications requiring multiple switching functions.
This relay belongs to the DRM series, which is engineered to withstand demanding industrial conditions with improved reliability and extended service life. It uses silver alloy contact material that ensures excellent conductivity and durability while minimizing wear caused by arcing.
The relay supports a switching AC voltage up to 250V ac, allowing it to control various AC loads. It features plug-in terminal types for easy and secure installation in control panels. The compact dimensions of 28mm height, 36mm width, and 21.5mm length enable fitting in confined spaces.
With a coil resistance of 630 ohms and coil power consumption of 0.9W, it delivers efficient performance with minimal power consumption. Its operating temperature range from -40°C to 60°C allows use in a wide array of industrial environments without performance degradation.
The DRM relay series incorporates design features such as series connected contacts and built-in blow magnets to effectively suppress arcing, resulting in longer relay life and reduced maintenance costs.
Compact design for panel mounting. Silver alloy contact material ensures durability. Low contact resistance reduces energy loss. Supports multiple industrial applications with 4PDT configuration. Wide operating temperature range for harsh environments.
Low coil power consumption of 0.9W. Plug-in terminals for easy installation. Minimized contact wear due to arcing suppression. This relay is suitable for electrical, automation, manufacturing, and industrial control panel applications.
Explore more Power Relays and components on EnvMart to find reliable solutions tailored to your industrial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay has a coil voltage of 24V dc, ensuring efficient actuation.
It supports a switching AC voltage of up to 250V ac, allowing it to control various AC loads.
The relay can handle a switching current of 5A, making it suitable for multiple switching functions.
This model features a 4PDT (Four Pole Double Throw) contact configuration.
The relay has dimensions of 28mm in height, 36mm in width, and 21.5mm in length.
The coil resistance is 630 ohms, contributing to its efficient performance.
It operates within a temperature range of -40°C to 60°C, suitable for various industrial environments.
It features plug-in terminals for easy and secure installation in control panels.
The relay uses silver alloy as the contact material, ensuring reliable conductivity.
The contact resistance is low at 50 milliohms, which minimizes power loss.
It complies with EAC and RoHS standards, ensuring adherence to safety and environmental regulations.
The coil power consumption is 0.9W, which contributes to its efficient operation.
