Schmersal AZM 300 Series Solenoid Interlock Switch Power to Lock 24V DC 100mA AZM300Z-ST-1P2P-A

Free Delivery in India | Lowest Global Shipping Charges

Schmersal AZM 300 Series Solenoid Interlock Switch Power to Lock 24V DC 100mA AZM300Z-ST-1P2P-A

Name: Schmersal AZM 300 Series Solenoid Interlock Switch Power to Lock 24V DC 100mA AZM300Z-ST-1P2P-A
Brand: SCHMERSAL
SKU: 135441
Price: 913.75 USD
Availability: InStock



Category Solenoid Interlock Switch Brand SCHMERSAL Condition New

Specifications

Country of Origin	Germany
Brand	Schmersal
Length	85mm
Model	AZM300Z-ST-1P2P-A
Depth	35mm
IP Rating	IP66, IP67, IP69K
Width	100mm
Housing Material	Plastic
Series	AZM 300
Terminal type	Plug-In
Supply Voltage	24V dc
Standards/Approvals	CSA, IEC, UL
Contact DC Voltage	26.4V dc
Contact AC Voltage	24V ac
Contact Current	100mA
Safety Contacts	2 PNP
Number of Auxiliary Contacts	1
Conduit Entry	1/2 in NPT

Key Features

Equipped with two PNP safety contacts and one PNP auxiliary contact for reliable operation.
Compact and robust design with dimensions 85mm length, 100mm width, and 35mm depth.
Features RFID technology to protect against tampering and unauthorized access.
IP66, IP67, and IP69K rated enclosure for high protection against dust and water ingress.
Compatible with series chain connections up to 200 metres for flexible system design.
Indicators include three LEDs for supply voltage, switching condition, and fault detection.
Suitable for automotive, robotics, rail industry, and transportation safety applications.
Complies with CSA, IEC, and UL standards for assured quality and safety.

Product Description

Schmersal AZM300Z-ST-1P2P-A Solenoid Interlock Switch Power to Lock 24V DC is designed to improve industrial site safety by preventing unintended machine operation and restricting access to hazardous areas. Its power to lock function ensures guarded areas remain secured until safe to operate.

The device incorporates two PNP safety contacts and one PNP auxiliary contact, providing high reliability in safety circuit implementations. Its compact plastic housing measures 85mm in length, 100mm in width, and 35mm in depth, providing easy integration into industrial environments while maintaining robust protection.

This switch uses advanced RFID technology for tamper resistance, guaranteeing device integrity and security. The enclosure meets IP66, IP67, and IP69K protection ratings, offering resistance against dust ingress, water jets, and high-pressure washdowns, suitable for demanding industrial conditions.

Three LEDs provide clear indication of supply voltage, switching states, and any functional faults, facilitating quick diagnostics and maintenance. The switch supports series chaining up to 200 metres, allowing flexible wiring configurations in complex systems.

Common applications include automotive manufacturing lines, robotic systems, and rail transport safety controls, where ensuring operator and machine safety is critical. The product complies with major international standards such as CSA, IEC, and UL, reflecting its safety and quality credentials.

Equipped with two PNP safety contacts and one PNP auxiliary contact for operational reliability. Compact dimensions with plastic enclosure providing IP66, IP67, and IP69K protection. RFID technology prevents tampering to maintain protection integrity.

Three LED indicators facilitate status and fault monitoring. Supports series chain lengths up to 200 metres for versatile system integration. Operates within an ambient temperature range of 0°C to +60°C. Compliant with CSA, IEC, and UL safety standards.

Ideal for automotive, robotics, rail industry, and transportation applications. Explore more Solenoid Interlock Switches and related products in the Electronics & Electricals category on EnvMart for reliable industrial safety solutions.
