Mentor GmbH Press-In 30-Way Right Angle Rigid LED Light Pipe Clear 1296.2023

Mentor GmbH 1296.2023 Press-In 30-Way Right Angle Rigid LED Light Pipe is engineered to transmit light effectively from PCB-mounted SMD LEDs to the interface with minimal luminance loss and no light bleed between adjacent elements. It features a rigid construction with a clear dome lens for precise light guidance in right angle orientation.

This LED light pipe assembly consists of 30 light pipes arranged in three horizontal rows and two columns, with individual light pipes having a 1.95mm outside diameter and 14.45mm length. The press-in mount type ensures secure attachment to printed circuit boards. Compliance with UL94 standard guarantees flame retardant properties suitable for industrial usage.

The product operates reliably in ambient temperatures between -40°C and +85°C. The inclusion of a light diffusing screen enhances viewing quality by preventing unwanted radiation and color mixing. While this assembly does not include LEDs, it is tailored to be used with surface mount LEDs for a variety of applications requiring precise light indication and display.

Ideal for use in electronic components, power and connectors, displays and optoelectronics, and LED lighting components within industrial, manufacturing, and commercial electronic systems.

The product has 30 ways arranged in a 3 x 2 configuration. It is a rigid, press-in mount type light pipe compatible with surface mount LEDs. The light pipe has a length of 14.45mm and an outside diameter of 1.95mm. The lens colour is clear with dome-shaped light pipes providing focused light output.

It meets UL94 standards for flammability compliance and operates in ambient temperatures from -40°C to +85°C. The horizontal light guides consist of three rows of round heads. Light pipes use a diffusing screen to prevent radiation from color combinations.

This product does not include LEDs but is designed for use with LEDs on circuit boards. Explore more LED Lighting Components from Mentor GmbH for high-quality optical performance and reliability within electronic assemblies and interface designs on EnvMart.
