Mentor GmbH Press-In 20-Way Right Angle Rigid LED Light Pipe Clear 1296.2012

Mentor GmbH 1296.2012 Press-In 20-Way Right Angle Rigid LED Light Pipe Clear is engineered to transmit light efficiently from surface-mount LEDs on PCBs to the user interface with minimal luminance attenuation and no light bleed between adjacent elements.

This product family consists of high-quality horizontal light guides configured in two rows, providing a compact solution for guiding LED light through dome-shaped rigid pipes measuring 11.85 mm in length and 1.95 mm in diameter. The rigid clear construction ensures durability in industrial and electronic environments.

The light pipes are mounted via a press-in mechanism that guarantees secure attachment to printed circuit boards, configured in a 2 x 1 row-column format delivering 20 ways of light transmission. Their right-angle orientation facilitates effective routing in constrained spaces, ensuring seamless integration into electronic devices and control panels.

Designed to operate reliably in ambient temperatures from −40°C to +85°C, these LED light pipes comply with UL94 flame retardancy standards, ensuring safety during operation. The clear lens color with dome-shaped ends produces precise light output without dispersion, enhancing user interface visibility and aesthetics in applications like instrumentation displays, industrial machines, and electronic control panels.

Constructed of durable, clear rigid plastic material designed for industrial use. Configuration of 20 light pipes arranged in two rows, each with right-angle orientation. Press-in mounting style for reliable installation onto PCBs.

Ambient temperature operating range from −40°C to +85°C ensures versatility. UL94 flame retardant certification enhances operational safety. Dome-shaped ends minimize light bleed for clearer signal indication. Manufactured in Germany for assured quality and precision.

This horizontal light guide is ideal for electronics manufacturers requiring reliable and effective LED light transmission components. It supports diverse industrial and commercial applications, including electronic instrumentation, measurement devices, and control system displays.
