Amphenol Industrial MIL Spec Circular Connector PT Copper Alloy Straight 4 Way 1kV AC 125°C PT06E-8-4S(SR)
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 1kV ac |
| Brand | Amphenol Industrial |
| Colour | Green |
| Orientation | Straight |
| Model | PT06E-8-4S(SR) |
| Mount Type | Cable |
| Housing Material | Aluminium |
| Contact Material | Copper Alloy |
| Series | PT |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Female |
| Connector Gender | Male |
| Shell Size | 8 |
| Military Standard | MIL-DTL-26482 |
| Mating Type | Bayonet |
| Connector Size | Miniature |
| Shell Plating | Cadmium |
Key Features
- Miniature 4 way copper alloy connector with gold plated female contacts.
- Bayonet coupling mechanism for secure and fast mating.
- Aluminium shell with cadmium plating provides durability and corrosion resistance.
- Cable mount connector with solder termination and strain relief.
- Compliant with MIL-DTL-26482 military standard.
- Operates from -55°C to 125°C in harsh environments.
- Rated for 1kV AC voltage suitable for industrial and military use.
- Green color shell size 8 for easy identification in wiring harnesses.
Product Description
Amphenol Industrial PT06E-8-4S(SR) MIL Spec Circular Connector is a rugged and high-performance electrical connector designed to meet the demanding requirements of military and industrial applications. Featuring a straight orientation and miniature size, this connector supports four female copper alloy contacts with gold plating to ensure excellent conductivity and corrosion resistance.
The aluminium shell is cadmium plated, providing enhanced durability and protection against environmental factors. It incorporates a bayonet coupling mechanism for secure and quick connection, making it ideal for applications demanding reliable interconnection with frequent mating and unmating.
Compliant with MIL-DTL-26482 Series 1 standards, this connector assures compatibility and interchangeability with other MIL-DTL-26482 connectors. It operates effectively from a minimum temperature of -55°C up to a maximum of 125°C, making it suitable for extreme environments.
The connector is designed for cable mounting with solder termination type contacts and features integrated strain relief for cable durability. Its 8 size shell and green color coding assist with identification in complex wiring harnesses.
This Amphenol PT series connector finds wide applications in aerospace, defense, industrial electronics, and communications equipment where robust, reliable, and high-voltage connectors are required.
This connector offers high density and reliable connections for power and signal circuits. Its gold plated copper alloy contacts resist wear and corrosion for long service life. The bayonet coupling ensures quick connect/disconnect operations without tools.
It withstands harsh environmental conditions, supporting military-grade applications. Manufactured to exacting standards, it supports up to 1kV AC voltage. The connector is supplied new and ready for installation in demanding industrial environments.
Explore more Amphenol Industrial products and Mil Spec Circular Connectors in the EnvMart catalog to find matching connectors and accessories for your projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for 1kV AC voltage, making it suitable for industrial and military applications.
It operates effectively from a minimum temperature of -55°C up to a maximum of 125°C, suitable for extreme environments.
This connector features four female contacts made from copper alloy with gold plating for enhanced conductivity.
It uses solder termination type contacts, ensuring a secure connection for cable mounting.
The housing is made of aluminium and is cadmium plated, providing durability and corrosion resistance.
The connector has a shell size of 8, which aids in identification within wiring harnesses.
It incorporates a bayonet coupling mechanism, allowing for secure and quick connections.
Yes, it is compliant with the MIL-DTL-26482 military standard, ensuring compatibility and interchangeability with other connectors of the same series.
The shell of this model is green, which helps with easy identification in complex wiring setups.
This connector features a straight orientation, suitable for various installation scenarios.
It finds applications in aerospace, defense, industrial electronics, and communications equipment, where robust connections are required.
The contacts are made from copper alloy and are gold plated to resist wear and corrosion.
