Phoenix Contact Pluggable Terminal Block MC 1.5/4-STZ1-3.5 Series, 4-Contact, 3.5 mm Pitch, Female Connector, 320 V 1767500
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 320V |
| Brand | Phoenix Contact |
| Colour | Green |
| Orientation | Straight |
| Current | 8A |
| Length | 41mm |
| Model | 1767500 |
| Depth | 11.6mm |
| Width | 14mm |
| Housing Material | Polyamide |
| Series | MC 1.5/4-STZ1-3.5 |
| Number of Rows | 1 |
| Pitch | 3.5mm |
| Number of Contacts | 4 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 0.14mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 16AWG |
| Wire Connection Method | Screw Connection with Tension Sleeve |
Key Features
- Constructed with durable green polyamide housing for electrical insulation and safety.
- Supports wire sizes from 0.14 mm² to 1.5 mm² and AWG 28 to AWG 16 for versatile wiring applications.
- Features screw connection with tension sleeve for secure wire fastening.
- Single-row configuration with a pitch of 3.5 mm suitable for PCB connectors.
- Nominal cross section of 1.5 mm² for reliable current carrying capacity of 8 A.
- Manufactured in Germany ensuring quality and compliance with industrial standards.
Product Description
Phoenix Contact 1767500 pluggable terminal block MC 1.5/4-STZ1-3.5 is a high-quality female PCB connector with 4 contact points and a 3.5 mm pitch, designed for industrial electronics and electrical assemblies.
This terminal block features a sturdy polyamide housing in green color providing excellent electrical insulation and durability. Rated for 320 V and a nominal current of 8 A, it supports a wide range of wire sizes from 0.14 mm² to 1.5 mm² (AWG 28 to AWG 16) ensuring flexible connectivity options.
The screw connection with tension sleeve mechanism ensures secure and reliable wire fastening, reducing maintenance needs and enhancing safety in electrical installations. Its compact size with length 41 mm, width 14 mm, and depth 11.6 mm makes it suitable for dense PCB layouts and industrial control panels.
Designed without locking mechanisms, this terminal block fits into the MINI COMBICON series with strain relief options such as the STZ1 strain relief measuring 9.9 x 25.5 mm. The connector offers a straight orientation and a single row with four positions, ideal for applications requiring compact and modular electrical connections.
Durable polyamide housing for improved electrical insulation and mechanical strength. Supports 4 contacts and offers a pitch of 3.5 mm for compact PCB mounting. Rated for 8 A nominal current and 320 V voltage for industrial applications.
Accommodates wire sizes from 0.14 mm² to 1.5 mm² with secure screw connection. Compact dimensions suitable for space-constrained electrical assemblies. Manufactured in Germany adhering to stringent quality standards.
This pluggable terminal block is widely used across electronics manufacturing, industrial automation, electrical control panels, and laboratory instrumentation setups where reliable and modular PCB connections are essential.
Explore more Phoenix Contact products and comprehensive industrial electrical components here on EnvMart.
Explore more products in our Pluggable Terminal Blocks category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for a voltage of 320 V, making it suitable for various industrial applications.
This model has a nominal current capacity of 8 A, which supports reliable electrical connections.
The pitch of this terminal block is 3.5 mm, suitable for compact PCB layouts.
It features a screw connection with a tension sleeve for secure wire fastening.
The dimensions are 41 mm in length, 14 mm in width, and 11.6 mm in depth, making it compact for various applications.
Yes, it is designed for industrial electronics and electrical assemblies, providing reliable and modular connections.
The housing is constructed from durable green polyamide, providing excellent electrical insulation.
It has 4 contacts, allowing for multiple connections in a single unit.
It is manufactured in Germany, ensuring adherence to stringent quality standards.
The connector has a straight orientation, making it easy to integrate into existing designs.
This model belongs to the MC 1.5/4-STZ1-3.5 series, which includes various configurations for different applications.
