Amphenol Limited MIL Spec Circular Connector Copper Alloy Straight 6 Way Panel Mount 400V 5A TV07ZN-09-35PN
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 400, 500V ac |
| Brand | Amphenol Limited |
| Colour | Black |
| Orientation | Straight |
| Current | 5A |
| Model | TV07ZN-09-35PN |
| Mount Type | Panel Mount |
| Housing Material | Aluminium |
| Contact Material | Copper Alloy |
| Series | TV |
| Termination Type | Solder |
| Maximum Operating Temperature | 175°C |
| Minimum Operating Temperature | -65°C |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Connector Gender | Female |
| Shell Size | 09 |
| Military Standard | MIL-DTL-38999 |
| Mating Type | Screw Coupling |
| Connector Size | Standard |
| Shell Plating | Black Zinc Nickel |
Key Features
- This connector has 6 contacts with male contact gender and female connector gender.
- The shell size is 09 with black zinc nickel shell plating for corrosion resistance.
- It uses MIL-DTL-38999 military standard and features screw coupling mating type.
- Operating temperature ranges from -65°C to 175°C, suitable for harsh environments.
- The contact material is copper alloy with gold plating ensuring reliable signal transmission.
- Termination is by solder, and the connector is straight in orientation.
- Housing material is aluminium with black color and includes strain relief for mechanical durability.
- Designed for up to 500 mating cycles and 500 hours salt spray endurance.
Product Description
Amphenol Limited TV07ZN-09-35PN MIL Spec Circular Connector is a high-performance, robust six-way circular connector designed for panel mount applications. It features a copper alloy construction with black zinc nickel plating for enhanced corrosion resistance and durability. Rated for 400V and 5A current, this connector meets the MIL-DTL-38999 Series III Class Z standard ensuring military-grade quality.
This straight connector includes six gold-plated contacts with male contact gender and a female connector gender suitable for secure connections in demanding environments. It supports an operating temperature range from -65°C up to 175°C, providing reliable functionality under extreme climatic conditions.
Manufactured with an aluminium housing and equipped with strain relief, this model ensures mechanical stability and resistance to environmental factors. The solder termination type allows for secure wiring connections. The screw coupling mating type guarantees firm coupling with corresponding parts, facilitating up to 500 mating cycles and offering a salt spray resistance of 500 hours for long-term durability.
This connector caters to military applications including aircraft, vehicles, communication devices, and submarine systems, as well as commercial uses requiring rugged and hard-wearing connectors.
The black zinc nickel plating is a RoHS compliant and ecological alternative to cadmium plating, favored in modern defense industry standards. This connector supports 6 contacts with male pin gender and female connector gender.
Rated for 400-500V AC voltage and 5A current, engineered to MIL-DTL-38999 military standard. Black zinc nickel plating provides corrosion resistance with up to 500 hours salt spray endurance. Gold plated copper alloy contacts ensure optimal conductivity and wear resistance.
Operating temperature range from -65°C to +175°C for versatile environmental tolerance. Panel mount design with screw coupling ensures secure installation. Aluminium housing with black color finish includes strain relief for enhanced durability.
Explore more from the Mil Spec Circular Connectors category at EnvMart for your industrial and military connector needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for 400V and 500V AC voltage.
The maximum operating temperature for this connector is 175°C.
It features six contacts with male contact gender and female connector gender.
The termination type for this connector is solder.
The shell size of this model is 09.
The housing material is aluminium with a black color finish.
This connector uses a screw coupling mating type for secure connections.
It offers a salt spray endurance of up to 500 hours.
This connector is rated for a current of 5A.
It complies with the MIL-DTL-38999 military standard.
The orientation of this connector is straight.
The country of origin for this connector is India.
