Phoenix Contact COMBICON Control Series Pluggable Terminal Block 3-Contact 5.08 mm Pitch 1 Row 400V 12A 1809089

Phoenix Contact 1809089 COMBICON Control Series Pluggable Terminal Block is a high-quality electrical connector designed specifically for PCB applications where stable and versatile connection is critical. Its 3-contact configuration with a 5.08 mm pitch and single-row arrangement provides ample connectivity options for industrial, laboratory, and manufacturing automation systems.

The terminal block housing is made of Polybutylene Terephthalate (PBT), which offers excellent mechanical strength and electrical insulation properties, making it suitable for demanding environments. The screw wire connection method accommodates wire sizes up to 2.5 mm², ensuring reliable clamp connections under vibration and electrical loads.

Rated at 12 amps and capable of handling up to 400 volts, this connector complies with a broad spectrum of safety and environmental standards, including CSA, China RoHS, cULus, EU RoHS, and EU REACH SVHC certifications. Its straight male connector simplifies assembly and offers a secure mating with corresponding female headers.

The compact size of 12 mm length and 25.4 mm width allows for efficient PCB space management without compromising connectivity. The green color is consistent with COMBICON Control series standards, supporting easy product identification.

Designed for wave soldering processes, the terminal block is optimized for automated manufacturing lines, ensuring high throughput and consistent quality in electronics production.

This product is particularly suited for industrial automation, control panels, power distribution boards, and other electronic equipment requiring modular and pluggable terminal connections.

The terminal block supports a maximum current rating of 12A for robust electrical performance. Constructed from durable Polybutylene Terephthalate housing material ensuring high insulation and mechanical stability. Features a straight male connector orientation for easy integration into PCBs.

Wire connection is secured by a screw method enabling firm clamping of wires up to 2.5 mm². Designed to operate safely up to 400 volts and meets multiple standards including CSA, CHINA RoHS, cULus, EU RoHS, and EU REACH SVHC.

Compact dimensions with a length of 12 mm and width of 25.4 mm optimize PCB space usage. Green coloration aids visual identification and conforms to industry norms. Compatible with wave soldering techniques facilitating mass production PCB assembly.

Originates from Germany, reflecting premium manufacturing quality. Explore more quality connectors and terminal blocks from Phoenix Contact and related products in the Electronics Components category at EnvMart.
