Weidmüller OMNIMATE SL Series Pluggable Terminal Block 4-Contact 3.5 mm Pitch 1 Row 320 V 17 A 1607060000

Weidmüller 1607060000 OMNIMATE SL Series Pluggable Terminal Block is a high-quality electrical connector designed for sophisticated PCB applications. This 4-contact, 3.5 mm pitch terminal block presents a compact footprint with a 1-row configuration ideal for both vertical and horizontal headers.

The terminal block supports a nominal voltage rating of 320 V and can carry a continuous current of up to 17 A, making it suitable for a wide range of power connections in industrial, telecommunications, automation, and electronic devices. Its housing is made of robust Polybutylene Terephthalate, providing excellent electrical insulation and mechanical stability.

The right-angle orientation and 3.2 mm solder pin length enable easy and consistent wave soldering on printed circuit boards with thicknesses of 1.6 mm or 2.0 mm. The connector is designed with a solder wire connection method, featuring a male connector gender, and is widely compatible within the OMNIMATE SL series ecosystem.

With physical dimensions of 10.7 mm length, 21 mm width, and 11.1 mm depth, this terminal block is optimized for space-saving circuit designs. Compliance with IEC 60664-1 and IEC 61984 standards ensures reliability and safety in demanding operational environments.

The bright orange coloration provides clear visual identification in crowded electrical panels and assemblies, facilitating maintenance and troubleshooting. Manufactured in Germany, this product adheres to stringent quality standards to guarantee long-term durability and performance.

Compact 3.5 mm pitch design for efficient PCB layout integration. 4-contact single-row configuration supporting various wiring needs. Durable Polybutylene Terephthalate housing for excellent insulation. Right-angle orientation with mounting optimized for wave soldering.

Male connector gender with solder wire connection method. Meets IEC 60664-1 and IEC 61984 international safety standards. Bright orange color for ease of identification. Manufactured in Germany for high quality and reliability.

This Weidmüller pluggable terminal block is widely used in electronics manufacturing, industrial automation, telecommunications equipment, and other commercial electronic assemblies requiring robust, reliable terminal connections. It integrates seamlessly with other components in the OMNIMATE SL series allowing modular wiring and configuration.
