ABB System Pro M Compact S200 Miniature Circuit Breaker 2-Pole 40A Type B 400V AC 125V DC 6 kA 2CDS252001R0405 S202-B40

Free Delivery in India | Lowest Global Shipping Charges

ABB System Pro M Compact S200 Miniature Circuit Breaker 2-Pole 40A Type B 400V AC 125V DC 6 kA 2CDS252001R0405 S202-B40



Category Miniature Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Germany
Range	System Pro M Compact
Brand	ABB
Height	88mm
Model	2CDS252001R0405 S202-B40
Depth	69mm
IP Rating	IP20, IP40
Width	35mm
Mount Type	DIN Rail
Current Rating	40A
Series	S200
Terminal type	Screw
Breaking Capacity	6kA
Number of Poles	2
Standards/Approvals	IEC/EN 60898-1, IEC/EN 60947-2
Rated AC Voltage	400V ac
Rated DC Voltage	125V
Tripping Characteristics	Type B
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal
Reset Actuator Type	Toggle Switch

Key Features

Designed for both commercial and industrial applications with reliable overload protection.
Features thermal tripping mechanism to ensure operational safety under varying temperatures.
Screw terminal type ensures secure and stable electrical connections.
Compact dimensions allow easy DIN rail mounting and space-efficient installation.
Type B tripping characteristics provide swift response to electrical overloads.
Constructed according to IEC/EN 60898-1 and IEC/EN 60947-2 standards.
IP20 and IP40 rated for protection against ingress of solid objects.
Designed for disassembly to facilitate end-of-life recycling and sustainability efforts.

Product Description

ABB 2CDS252001R0405 S202-B40 System Pro M Compact S200 series miniature circuit breaker offers dependable electrical protection for commercial and industrial settings. Rated at 40 amperes with 2 poles, this device handles alternating current at 400 volts and direct current at 125 volts. It is capable of interrupting fault currents up to 6 kiloamperes, ensuring circuit safety and preventing damage to connected equipment.

Equipped with a thermal tripping mechanism, the breaker reliably responds to overload conditions by disconnecting the circuit to prevent overheating. Its compact width of 35mm and depth of 69mm enables efficient use of panel space, and it mounts easily onto standard DIN rails. Screw-type terminals guarantee firm connections that resist loosening over time. The tripping characteristics correspond to Type B, providing prompt reaction to typical residential and light commercial overloads.

Manufactured in Germany to IEC and EN standards 60898-1 and 60947-2, this ABB S200 breaker meets stringent safety, performance, and environmental criteria. It carries IP20 and IP40 ratings, protecting internal components from solid foreign objects and dust. The toggle switch actuator provides quick manual reset capability after a trip event.

Designed for disassembly, the product contributes to sustainable practices by easing recycling and reuse of materials at end of life, in accordance with the ABB Better World initiative. This Miniature Circuit Breaker is suitable for integration with auxiliary contacts and accessories where enhanced circuit monitoring or control is needed.

Designed for commercial and industrial electrical circuit protection. Thermal tripping offers dependable overload protection. Compact DIN rail mountable form factor for space efficiency. Screw terminals for stable and secure wiring.

Meets IEC/EN international safety and performance standards. Type B trip characteristic suitable for common applications. IP20 and IP40 rated enclosure protection levels. Facilitates product disassembly to support recycling efforts.

Toggle switch actuator for reset convenience. Explore the ABB System Pro M Compact series and other circuit protection solutions at EnvMart for reliable industrial and commercial electrical safety.
