KYOCERA AVX 22 nF Multilayer Ceramic Capacitor 100V DC ±10% Tolerance Axial Solder CK06BX223K

KYOCERA AVX CK06BX223K is a high-quality multilayer ceramic capacitor designed for advanced electronic applications. Featuring a 22 nF capacitance and a voltage rating of 100V DC, this axial solder mount component offers excellent electrical stability and reliability. The capacitor uses X7R dielectric material, suitable for bypass, decoupling, filtering, sample and hold, and timing circuits.

The CK series capacitors from KYOCERA AVX are engineered for durability, meeting strict industrial requirements. With a tolerance of ±10%, this capacitor ensures consistent performance under varying electrical loads. It operates across a wide temperature range from −55°C to 125°C, making it ideal for automotive and industrial electronics where temperature variations are critical.

This capacitor has precise dimensions with 7.37 mm length and height, 2.29 mm width, a lead spacing of 5.08 mm, and lead diameter of 0.64 mm, allowing for straightforward PCB mounting and integration. The product complies with RoHS environmental standards, ensuring it meets current regulatory demands for hazardous materials.

Its radial leaded axial form factor simplifies soldering and wave solder processes in mass production. The capacitor is designed to support applications in consumer electronics, industrial equipment, automotive electronics, and telecommunications, delivering reliable energy storage and signal filtering capabilities.

Set within the CK series, this model is recognized for industry-standard specifications, catering to designers requiring proven performance in multilayer ceramic capacitors. The tape & reel packaging further facilitates automated manufacturing assembly lines, improving efficiency and reducing handling damage during transport.

Capacitance value of 22 nanofarads suitable for various electronic circuits. Axial solder mount type providing ease of installation on circuit boards. X7R dielectric material ensures stability across temperatures. Operates reliably within −55°C to 125°C temperature range.

Manufactured to comply with RoHS standards for environmental safety. Lead spacing is 5.08 mm with lead diameter of 0.64 mm for precise connections. Dimensions are 7.37 mm length, 7.37 mm height, and 2.29 mm width. CK series capacitor built for high reliability and quality performance.
