onsemi Undervoltage Detector Reset Controller 8-Pin SOIC 4.7 V Threshold MC34064D-005G
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.75mm |
| Length | 5mm |
| Model | MC34064D-005G |
| Width | 4mm |
| Mount Type | Surface |
| Series | MC34064 |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Sub Type | Reset Controller |
| Minimum Operating Temperature | 0°C |
| Pin Count | 8 |
| Maximum Supply Voltage | 6.5V |
| Minimum Supply Voltage | 1V |
| Number of Supervisors | 1 |
| Output Driver | Open Collector |
| Reset Threshold Voltage | 4.7V |
| Monitored Voltage | 5V |
Key Features
- Single supervisor reset controller designed for monitoring supply voltage.
- Surface mount SOIC package with 8 pins ensuring compact assembly.
- Operates with supply voltage range from 1 V to 6.5 V.
- Reset threshold voltage set at 4.7 V to ensure reliable undervoltage detection.
- Operating temperature range from 0°C to 70°C suitable for industrial environments.
- Open collector output driver compatible with various microprocessor systems.
- Series MC34064 device optimized for microprocessor supervisory applications.
Product Description
onsemi MC34064D-005G is a precise undervoltage detector and reset controller integrated circuit packaged in an 8-pin SOIC surface mount. It is designed for microprocessor supervisory and reset functions, providing critical monitoring of supply voltage in electronic systems.
This device monitors power supply voltages ranging between 1 V minimum and 6.5 V maximum. With a reset threshold voltage fixed at 4.7 V, it ensures system microprocessors are reset when voltage falls below operational levels, enhancing system reliability and preventing erratic functioning.
The device features a single supervisor without watchdog timer or manual reset options, and utilizes an open collector output driver to interface efficiently with external systems. It operates safely within a temperature range of 0°C to 70°C and meets typical industrial application requirements.
Compact in size with dimensions of 5 mm length, 4 mm width, and 1.75 mm height, this surface mount SOIC package enables space-saving on PCBs. The MC34064 series devices by onsemi are widely used in desktops, laptops, portable battery-powered equipment, and multiple-output power supplies, providing robust supply voltage supervision.
Single supervisor reset monitoring for stable voltage detection. Surface mount SOIC 8-pin form factor for easy PCB integration. Wide supply voltage range from 1 V to 6.5 V enhances versatility. Reset threshold precisely at 4.7 V ensures system stability.
Open collector output compatible with many microcontroller reset inputs. Operating temperature range 0°C to 70°C suitable for standard industrial uses. Compact package size minimizing board footprint. Ideal for industrial, computing, battery-powered, and measurement instrument applications.
Explore EnvMart's Electronics Components category for more voltage detection and supervisory ICs from leading manufacturers like onsemi.
Explore more products in our Voltage Detectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range from 1 V to 6.5 V, making it versatile for various applications.
The reset threshold voltage is fixed at 4.7 V, ensuring reliable undervoltage detection for connected systems.
It operates safely within a temperature range of 0°C to 70°C, suitable for standard industrial environments.
It features an open collector output driver, which is compatible with various microprocessor systems for efficient interfacing.
This unit has dimensions of 5 mm in length, 4 mm in width, and 1.75 mm in height, allowing for compact PCB assembly.
The MC34064D-005G includes a single supervisor for monitoring supply voltage.
It comes in an 8-pin SOIC surface mount package, which facilitates compact assembly on PCBs.
This reset controller is ideal for industrial, computing, battery-powered, and measurement instrument applications.
The device is designed to monitor a voltage of 5 V, ensuring system stability during operation.
No, this device does not include a watchdog timer or manual reset options; it functions solely as a supervisor reset controller.
The country of origin for this reset controller is India.
It belongs to the MC34064 series, which is optimized for microprocessor supervisory applications.
