Otto P9 Series Push Button Switch Momentary Panel Mount 0.5 in Cutout SPDT Black LED IP68 28 V dc 115 V ac P9113122W

Otto P9113122W is a high-quality P9 Series push button switch featuring momentary action designed for panel mounting applications with a 0.5 inch cutout size. It offers a Single Pole Double Throw (SPDT) contact configuration with a black actuator colour and black LED indicator.

This rugged push button switch is sealed to IP68 standards, providing watertight protection and is submersible up to 1 meter water pressure, making it suitable for demanding industrial environments. The threaded body allows secure hex nut mounting with a compact 12mm behind-panel depth for applications with limited space.

Rated for a contact current of 5 A at 28 V dc or 115 V ac, the switch features a low contact resistance enabling low-level switching capability. Operating temperature ranges from -55°C to +85°C ensures reliable performance in harsh conditions. The P9 series is precision engineered to withstand approximately 1 million mechanical operations and 25,000 electrical cycles, ensuring durability and longevity.

This switch is ideal for use in control panels, heavy machinery, computers, instrumentation, and other industrial or automation equipment where an attractive, reliable momentary push button is needed. It is supplied complete with a mounting nut and panel seal gasket for enhanced environmental sealing and easy installation.

Momentary operation with On-On switch configuration for precise control. Black actuator colour with black LED for integrated indication. Threaded body with nut and panel seal gasket included for robust mounting. Rated for 5A at 28 V dc and 115 V ac with low contact resistance.

Sealed to IP68 for watertight performance, submersible up to 1 meter water pressure. Operates reliably between -55°C and 85°C ambient temperature range. Suitable for industrial, heavy equipment, and control panel applications.

Compact size with approximately 12mm behind-panel depth for space saving. Mechanical life expectancy of 1 million operations and electrical life of 25,000 operations. Supplied with mounting nut and panel seal gasket for excellent environmental resistance.

This Otto push button switch is RoHS compliant and ideal for industrial, automation, control system, and heavy equipment applications requiring robust, waterproof panel switches. Explore the Electronics & Electricals category at EnvMart for additional Push Button Switches and electrical components.
