ABB High Performance S800N 2-Pole Miniature Circuit Breaker, 80A, Type C, 690V AC, 250V DC, 36kA Breaking 2CCG001229R0001
Specifications
| Country of Origin | Switzerland |
|---|---|
| Range | High Performance |
| Brand | ABB |
| Height | 95mm |
| Model | 2CCG001229R0001 |
| Depth | 88.5mm |
| IP Rating | IP20 |
| Width | 54mm |
| Mount Type | DIN Rail |
| Current Rating | 80A |
| Series | S800N |
| Terminal type | Screw |
| Breaking Capacity | 36kA |
| Number of Poles | 2 |
| Standards/Approvals | IEC/EN 60898-1, IEC/EN 60947-2 |
| Rated AC Voltage | 690V ac |
| Rated DC Voltage | 250V dc |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Electromagnetic, Thermomagnetic |
| Reset Actuator Type | Toggle Switch |
Key Features
- Provides reliable overload and short circuit protection with Type C tripping characteristics.
- Rated for 690V AC and 250V DC applications ensuring versatile use.
- High breaking capacity of 36kA for enhanced safety against electrical faults.
- Durable toggle switch actuator allows easy operation and reset.
- Compact DIN rail mount design for efficient panel installation.
- Compliance with IEC/EN 60898-1 and IEC/EN 60947-2 standards guarantees quality and safety.
- Operates reliably within temperature range of -25 to +60°C.
- IP20 rating protects against solid object ingress, suitable for indoor environments.
Product Description
ABB 2CCG001229R0001 is a High Performance S800N Series Miniature Circuit Breaker designed to offer effective electrical protection for industrial and commercial installations. This 2-pole MCB provides a robust current rating of 80 amperes with a Type C tripping characteristic, ideal for general purpose overload and short circuit protection.
The device supports rated AC voltage up to 690V and DC voltage up to 250V, enabling versatile application across various electrical systems. It features an impressive breaking capacity of 36kA, ensuring high safety under fault conditions.
Its compact dimensions of 54mm width, 95mm height, and 88.5mm depth allow easy integration onto DIN rails in electrical distribution panels. The toggle switch actuator facilitates quick resetting and user-friendly operation. Constructed according to IEC/EN 60898-1 and IEC/EN 60947-2 standards, this circuit breaker meets international safety and performance benchmarks.
This MCB is designed to operate reliably within a temperature range of -25°C to +60°C and has an IP20 ingress protection rating, suitable for indoor electrical environments. The tripping mechanism combines electromagnetic and thermomagnetic responses for precise circuit protection.
Reliable overload and short circuit protection with Type C tripping characteristics. Rated for 690V AC and 250V DC applications. High breaking capacity of 36kA enhances electrical safety. Toggle switch actuator allows easy reset and operation.
Compact DIN rail mount design for panel integration. Conforms to IEC/EN 60898-1 and IEC/EN 60947-2 standards. Operates within -25 to +60°C temperature range. Equipped with electromagnetic and thermomagnetic tripping mechanism.
Applications include electrical panels that require reliable circuit protection in industrial automation systems, commercial building electrical loads, and machinery protection. The product originates from Switzerland, emphasizing premium build quality and durability.
Explore the Electronics & Electricals category on EnvMart for more high quality circuit breakers and related electrical protection devices.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 80A, making it suitable for general purpose overload and short circuit protection.
It features a high breaking capacity of 36kA, ensuring enhanced safety against electrical faults.
The circuit breaker is rated for 690V AC and 250V DC applications, providing versatility across various electrical systems.
The dimensions of this circuit breaker are 54mm in width, 95mm in height, and 88.5mm in depth, allowing for compact installation.
It is designed for DIN rail mounting, which facilitates efficient installation in electrical distribution panels.
This model features Type C tripping characteristics, which are suitable for general purpose applications.
It operates reliably within a temperature range of -25°C to +60°C, making it suitable for various environments.
It complies with IEC/EN 60898-1 and IEC/EN 60947-2 standards, ensuring quality and safety in electrical applications.
This circuit breaker utilizes an electromagnetic and thermomagnetic tripping mechanism for precise circuit protection.
It has an IP20 rating, which protects against solid object ingress, making it suitable for indoor environments.
It features a toggle switch actuator that allows for easy operation and quick resetting.
The product originates from Switzerland, emphasizing its quality and build standards.
