Schneider Electric Residual Current Circuit Breaker with Overload Protection 25A Current Rating 3-Pole 300mA Trip A9DP7725

Schneider Electric A9DP7725 Residual Current Circuit Breaker with Overload Protection is an advanced electrical protection device designed for residential, distribution, and industrial use. It combines overcurrent and earth leakage protection through a thermal magnetic trip mechanism, ensuring rapid response to short circuits and overload conditions.

This model features a 25A current rating and a 3-pole design with 300mA earth leakage trip sensitivity. It is engineered for installation on standard DIN rails, making it suitable for a wide range of electrical panels and setups.

The device has a rated AC voltage of 400V AC and a breaking capacity of 10kA, capable of interrupting fault currents safely without damage. With a toggle switch actuator type and clear ON/OFF trip indication, it offers easy operation and maintenance.

Compact in size with a width of 90mm, height of 93mm, and depth of 73mm, this circuit breaker meets RoHS compliance and EN/IEC 60947-2 standards, reflecting its high-quality manufacturing. Its impulse withstand voltage of 4 kV and operational temperature range of -5 to 60°C make it reliable in demanding electrical environments.

Additional features include padlock capability for enhanced security during maintenance and Schneider Green premium classification highlighting its environmental sustainability.

This product is manufactured in Spain and ideal for use in electrical distribution boards, ensuring overcurrent and earth leakage protection in residential, commercial, and industrial installations.

Equipped with thermal magnetic trip unit technology for reliable overload and short circuit protection. Type C tripping characteristic suitable for residential and distribution applications. Features a toggle switch reset actuator with ON/OFF and trip indicators.

Mounts easily on DIN rail for convenient installation. Rated for 400V AC voltage and breaking capacity of 10kA. Compliant with RoHS and EN/IEC 60947-2 standards for quality assurance. Compact dimensions: 90mm width, 93mm height, and 73mm depth.

Designed for operational ambient temperatures between -5 to 60°C with 95% relative humidity tolerance. Impulse withstand voltage of 4 kV ensures durability under electrical stress. Padlockable for additional safety and security measures.
