Cooper Bussmann xEffect Eaton Moeller Miniature Circuit Breaker 1 Pole 6A Type C 415V AC 48V DC 10kA 102084 FAZ-C6/1-NA

Eaton 102084 FAZ-C6/1-NA Miniature Circuit Breaker, part of the xEffect Eaton Moeller FAZ Series, is a compact and reliable solution for circuit protection in industrial, commercial, and residential electrical systems. Rated at 6 amps with single pole configuration, this Type C breaker reacts instantaneously to current surges between five and ten times its rated current, effectively preventing damage from short circuits and overload situations.

The breaker supports a broad AC voltage range up to 415 volts and DC voltage rating of 48 volts, making it suitable for various applications, including lighting circuits, industrial machinery control, and power distribution boards. The thermal magnetic tripping mechanism combines fast electromagnetic response to short circuits with thermal overload protection, ensuring reliable and safe operation.

Designed to be installed on DIN rails, the device features a screw terminal connection system for secure and straightforward wiring. The toggle switch allows users to easily reset the breaker while providing clear indication of the contact status. The FAZ-C6/1-NA model's compact size permits installation in tight electrical enclosures, with dimensions of 66 mm width, 80 mm height, and 80 mm depth.

Safety features are enhanced by the finger-proof construction to prevent accidental contact and a trip-free mechanism that guarantees the breaker will trip during fault conditions even if the handle is held in the ON position. It complies with Eaton's xEffect design standards for fast short-circuit interruption, reducing electrical and mechanical stresses on connected equipment.

This miniature circuit breaker is ideal for electrical distribution panels in industrial automation, manufacturing plants, commercial buildings, and residential installations, where reliable protection of electrical circuits is crucial. Eaton's FAZ series offers wide versatility, with additional options for various current ratings and pole configurations.

Single-pole, 6A current rating circuit breaker. Type C tripping characteristic for moderate inrush currents. Thermal magnetic trip mechanism for overload and short circuit protection. Rated for 415V AC and 48V DC operation.

Breaking capacity of 10,000 amperes for fault interruption. Screw terminal type for secure electrical connections. Compact DIN rail mount design for efficient panel setups. Finger-proof and trip-free for enhanced safety.

Clear toggle switch indication for easy status monitoring. Compact dimensions suitable for tight spaces.

Explore the Eaton xEffect range of Miniature Circuit Breakers at EnvMart for dependable, high-performance circuit protection solutions tailored to industrial, commercial, and residential environments.
