KEMET R75 Polypropylene Capacitor, 5% Tolerance, 390 nF Capacitance, 1.25 kV DC, 600V AC Through Hole Mount R75RR339050H4J
Specifications
| Country of Origin | China |
|---|---|
| Brand | KEMET |
| Height | 33mm |
| Length | 32mm |
| Model | R75RR339050H4J |
| Packaging | Tape & Reel |
| Width | 18mm |
| Mount Type | Through Hole |
| Series | R75 |
| Maximum Operating Temperature | 105°C |
| Tolerance | 5 % |
| Capacitance | 390nF |
| Minimum Operating Temperature | -55°C |
| Dissipation Factor | 0.05% |
| Lead Length | 25mm |
| Standards/Approvals | RoHS, IEC 60286-2 |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 600V ac |
| Rated DC Voltage | 1.25kV dc |
| Lead Pitch | 27.5mm |
| Lead Diameter | 0.8mm |
| Automotive Standard | AEC-Q200 |
| Equivalent Series Resistance ESR | 8.2mΩ |
Key Features
- Rated DC voltage of 1.25 kV and AC voltage of 600 V ensures high voltage handling.
- Encapsulated in a self-extinguishing plastic case with thermosetting resin for durability.
- Lead pitch is 27.5 mm with tinned radial leads and lead length of 25 mm.
- Operating temperature range from -55°C to 105°C suitable for harsh environments.
- Low dissipation factor of 0.05% and equivalent series resistance of 8.2 mΩ for efficient performance.
- Compliance with RoHS and IEC 60286-2 standards ensures safe and reliable use.
- Ideal for silicon controlled rectifier, resonant circuit, and high frequency medium to high current applications.
- Plastic package/case protects capacitor and provides mechanical stability.
Product Description
KEMET R75RR339050H4J polypropylene capacitor is a high-performance film capacitor with a capacitance of 390 nF and a tolerance of 5%, designed primarily for through hole mounting. This capacitor features a rated DC voltage of 1.25 kV and an AC voltage rating of 600 V, making it suitable for use in high voltage electronic circuits requiring reliable performance.
The capacitor's construction includes metallized polypropylene film with radial tinned leads spaced 27.5 mm apart, having a lead length of 25 mm and diameter of 0.8 mm. Encased in a plastic case made of self-extinguishing, solvent resistant thermosetting resin material, it offers excellent mechanical protection and safety during operation.
Measuring 33 mm in height, 32 mm in length, and 18 mm in width, the device fits well into dense circuit assemblies. It operates reliably between -55°C and 105°C, guaranteeing stability across a wide temperature range. The low equivalent series resistance (ESR) of 8.2 mΩ and low dissipation factor of 0.05% minimize power losses during high frequency operation.
This capacitor meets automotive standard AEC-Q200 and complies with RoHS and IEC 60286-2 standards, ensuring environmental safety and quality. It is ideal for use in silicon controlled rectifier circuits, resonant circuits, and medium to high current high frequency applications.
Rated for 1.25 kV DC and 600 V AC voltage operation. High temperature tolerance from -55°C to 105°C. Self-healing metallized polypropylene film dielectric for increased longevity. Radial lead mounting with 27.5 mm lead pitch and 0.8 mm lead diameter.
Plastic self-extinguishing case for safety and durability. Compliance with RoHS and IEC 60286-2 regulations. Low ESR and dissipation factor enable efficient high-frequency operation. Automotive grade AEC-Q200 qualification.
Application suitability for silicon controlled rectifiers and resonant circuits.
This KEMET polypropylene capacitor series provides robust, reliable performance in industrial, automotive, and electronic applications requiring stable capacitance and high voltage endurance. Explore more Film Capacitors in the Electronics Components category on EnvMart for your specific needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this capacitor is 390 nF with a tolerance of 5%.
It has a rated DC voltage of 1.25 kV and an AC voltage rating of 600 V.
This capacitor operates reliably within a temperature range of -55°C to 105°C.
The equivalent series resistance (ESR) is 8.2 mΩ, which helps minimize power losses during operation.
The dimensions of this model are 33 mm in height, 32 mm in length, and 18 mm in width.
It is designed for through hole mounting.
The lead pitch is 27.5 mm and the lead diameter is 0.8 mm.
It complies with RoHS and IEC 60286-2 standards, ensuring environmental safety and quality.
This model is ideal for silicon controlled rectifiers, resonant circuits, and medium to high current high frequency applications.
It is packaged in tape and reel format for convenience in handling and assembly.
The dissipation factor is 0.05%, which contributes to its efficiency in high frequency applications.
This capacitor meets the automotive standard AEC-Q200, indicating its suitability for automotive applications.
