Belimo Modulating Damper Actuator 10 Nm Torque 24V AC/DC Supply NM24A-SR-TP

Belimo NM24A-SR-TP modulating damper actuator is engineered for precise control in heating, ventilation, and air conditioning (HVAC) systems. Featuring a torque of 10 Nm and operable with a 24V AC/DC power supply, this actuator offers efficient and reliable damper positioning.

Designed to accommodate damper areas up to 2 square meters, it provides compatibility with a variety of ventilation installations. The actuator includes a switch for manual override and a visible position indicator, allowing for ease of maintenance and operation.

Built with stall torque technology, it eliminates the need for end switches, enhancing longevity with a minimum life expectancy of 60000 operations. The device operates quietly at 35 dB with IP54 rating, offering protection from dust and moisture, suitable for industrial and commercial HVAC environments.

The angle of rotation is 95°, completing adjustments within 150 seconds. It supports damper spindles sized between 8 mm and 26.7 mm, with adjustable U-clamp for both round and square shafts. Operating temperature ranges from -30°C to 50°C, making it adaptable to diverse climatic conditions.

Compliance with industry certifications such as UL, CSA, RoHS, EN, IEC, and CE assures product quality and safety. Manufactured in Switzerland, this actuator is ideal for applications in industrial ventilation, air conditioning, and thermal management systems.

Operates with a maximum damper area of 2 square meters for effective air control. Equipped with a modulating control type for precise damper positioning. Includes a switch for manual override and control flexibility. Power consumption is low at 2 watts, ensuring energy efficiency.

IP54 rating provides protection against dust and water ingress. The Actuator features a noise level of 35 dB ensuring quiet operation. Operates within a temperature range of -30°C to 50°C for diverse environments. Running time is 150 seconds with a 95-degree angle of rotation for accurate damper adjustment.

Compatible with damper spindle sizes ranging from 8 mm to 26.7 mm. Manufactured in Switzerland with compliance to UL, CSA, RoHS, EN, IEC, and CE standards. Explore more HVAC and automation control solutions within our comprehensive EnvMart catalog to meet diverse industrial needs.
