Lovato Modulo Miniature Circuit Breaker 2-Pole 40A Type D 400V AC 80V DC 10kA Breaking Capacity P1MB

Lovato P1MB Miniature Circuit Breaker Model P1MB2PD40 is a high-quality 2-pole protection device designed for industrial and commercial electrical installations. With a 40 ampere current rating and Type D tripping characteristics, it effectively protects circuits that experience moderate to high inrush currents such as motors and transformers.

This circuit breaker supports both AC and DC circuits, rated at 400 volts AC and 80 volts DC, and can interrupt fault currents up to 10 kiloamperes, providing dependable protection in demanding operational environments. Its thermal magnetic tripping mechanism ensures fast response to overcurrent and short circuit conditions.

The device is engineered for DIN rail mounting, facilitating easy integration into electrical panels. Screw terminal types provide robust and reliable wiring connections, ensuring stable electrical contact. The compact form factor with a height of 86.5mm, width of 36mm, and depth of 80mm makes it ideal for use in constrained panel spaces.

Compliance with multiple regional and international standards such as IEC, UL, CSA, and others guarantees product safety and performance. The IP20 rated enclosure offers protection against access to hazardous parts by fingers or objects greater than 12mm, suitable for indoor electrical cabinet applications.

Supports 2 poles with a current rating of 40 amperes. Type D thermal magnetic tripping mechanism for protection against overload and short circuits. Rated operational voltage of 400V AC and 80V DC. Breaking capacity of 10kA ensures reliable fault current interruption.

Designed for DIN rail mounting in standard electrical enclosures. Screw terminals facilitate secure and easy wiring connections. Compact dimensions allow integration in limited spaces. Conforms to EAC, IEC/EN/BS 60898-1, IEC/EN/BS 60947-2, UL 1077, CSA, and cURus standards.

IP20 enclosure rating protects against solid objects and finger access.

This Miniature Circuit Breaker is ideal for use in electrical distribution panels in industries, commercial buildings, and automation systems. It provides efficient circuit protection to ensure safety and longevity of electrical infrastructure.
