Honeywell Technologies Pin Plunger Micro Switch, 5A, 250 V AC, SPCO Contact, IP40 Rating V19S05-HZ015A03
Specifications
| Country of Origin | China |
|---|---|
| Brand | Honeywell |
| Length | 27.8mm |
| Model | V19S05-HZ015A03 |
| Depth | 15.9mm |
| IP Rating | IP40 |
| Width | 10.3mm |
| Housing Material | Polybutylene Terephthalate |
| Series | V19 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPCO |
| Actuator Type | Pin Plunger |
| Minimum Operating Temperature | -25°C |
| Standards/Approvals | cUL, CQC, CSA, ENEC, RoHS, UL |
| Switch Contact Current | 5A |
| Operating Force | 0.15N |
| Mechanical Life | 1000000Cycles |
| Contact AC Voltage | 250V ac |
| Microswitch Type | Unsealed |
Key Features
- The actuator type is a precise pin plunger ensuring accurate contact actuation.
- Designed with a SPCO (Single Pole Change Over) contact configuration.
- Constructed with durable Polybutylene Terephthalate housing for robust performance.
- Provides an IP40 ingress protection rating to prevent solid particle intrusion.
- Operating force is minimal at 0.15N for ease of use and longevity.
- Operates reliably within the temperature range of -25°C to 85°C.
- Unsealed micro switch type suitable for cost-effective and high-volume applications.
- Mechanical life expectancy of 1,000,000 cycles ensures extended durability.
Product Description
Honeywell V19S05-HZ015A03 Pin Plunger Micro Switch is a high-quality, unsealed micro switch designed for electronic and electrical applications requiring precise switching operations. It is engineered to offer reliable and repeatable performance with a contact current rating of 5A and contact voltage of 250V AC, making it ideal for control and auxiliary function systems.
The micro switch features a pin plunger actuator type that delivers accurate and responsive switching. The switch contact is configured as SPCO (Single Pole Change Over) which allows versatile circuit designs. It is housed in Polybutylene Terephthalate, a material known for its mechanical strength and resistance to heat.
With an IP40 rating, it ensures protection against ingress of solid particles larger than 1mm, suitable for general indoor use. The operating force of 0.15N promotes ease of actuation, contributing to its long mechanical life rated for one million cycles, offering durability and maintenance-free performance.
This micro switch operates reliably within a temperature range from -25°C to 85°C, making it suitable for varied environmental conditions. Its compact dimensions (length 27.8mm, width 10.3mm, depth 15.9mm) enable easy installation in constrained spaces commonly found in industrial and electronic assemblies.
The actuator is a pin plunger providing exact triggering. Contact configuration SPCO supports single pole change-over functionality. Robust polybutylene terephthalate housing increases durability. IP40 rating provides protection against solid object ingress.
Low operating force of 0.15N enhances performance and user ease. Unsealed design suits high volume, cost-sensitive applications. Mechanical life of one million cycles ensures longevity. Compact form factors fit diverse mounting requirements.
Certified under multiple international standards for assured quality. Manufactured in China in compliance with rigorous quality controls.
Commonly used in industrial control systems, automation equipment, HVAC controls, and manufacturing machinery, this Honeywell micro switch is trusted for its precision and reliability.
Explore our Honeywell Micro Switch range at EnvMart for high-quality industrial electrical components that meet your application demands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The contact current rating of this micro switch is 5A.
The switch contacts are rated for 250V AC.
It operates reliably within a temperature range of -25°C to 85°C.
The mechanical life expectancy of this micro switch is rated for 1,000,000 cycles.
This model uses a pin plunger actuator type for precise contact actuation.
It has an IP40 ingress protection rating, which prevents solid particle intrusion larger than 1mm.
The housing is constructed from Polybutylene Terephthalate, known for its mechanical strength and heat resistance.
The operating force is minimal at 0.15N, promoting ease of use.
The dimensions are 27.8mm in length, 10.3mm in width, and 15.9mm in depth.
It features a Single Pole Change Over (SPCO) contact configuration, allowing versatile circuit designs.
This micro switch is certified under cUL, CQC, CSA, ENEC, RoHS, and UL standards.
It is commonly used in industrial control systems, automation equipment, HVAC controls, and manufacturing machinery.
