ABB Residual Current Circuit Breaker with Overload Protection 13A Current Rating 1-Pole 30 2CSA255103R1134 DS-ARC1 C13 A30



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	System Pro M Compact
Brand	ABB
Height	85mm
Model	2CSA255103R1134 DS-ARC1 C13 A30
Depth	69mm
Width	52.5mm
Mount Type	DIN Rail
Current Rating	13A
Series	DS-ARC1
Terminal type	Screw
Breaking Capacity	6kA
Number of Poles	1
Standards/Approvals	IEC, RoHS
Rated AC Voltage	240V ac
Tripping Characteristics	Type C
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Trip Sensitivity	30mA
Earth Leakage Protection Type	Type A
Supply possible both from top and bottom side	double slots available for connection with cables and busbars

Key Features

Provides integrated residual current and overload protection in a compact 1-pole design.
Thermal magnetic tripping mechanism with Type C characteristics for precise fault response.
Mounts easily on DIN rail with screw terminals for secure installation.
Rated for 240V AC operation with a breaking capacity of 6 kA.
Equipped with toggle switch reset actuator and LED indicators for easy status monitoring.
Suitable for protecting circuits against arc faults, overvoltages, and earth fault currents.
Features dual supply slots allowing wiring from both top and bottom sides.
Complies with IEC standards and RoHS environmental directives.

Product Description

ABB 2CSA255103R1134 DS-ARC1 C13 A30 Residual Current Circuit Breaker with Overload Protection is a single-pole device designed for precise and reliable electrical circuit protection in industrial and commercial applications. Rated at 13A current and 240V AC voltage, this RCBO features an integrated residual current function combined with overcurrent protection using a thermal magnetic tripping mechanism with Type C characteristics, providing effective safeguarding against short circuits and overloads.

With a high breaking capacity of 6 kA, the device ensures safety during fault conditions and incorporates type A earth leakage protection with 30 mA sensitivity to protect personnel from electrical shocks. The toggle switch actuator allows for easy manual reset, and built-in LED indicators facilitate quick troubleshooting and monitoring of circuit status.

The product is part of the DS-ARC1 series within the System Pro M Compact range, designed for modular DIN rail mounting. Installation is simplified through screw terminal connections and dual supply slots for wiring from both top and bottom sides, compatible with System Pro M Compact® busbars and accessories.

Its compact size (Height 85mm, Width 52.5mm, Depth 69mm) suits electrical distribution boards with limited space, making it ideal for residential, commercial, and light industrial electrical panels. Manufactured in Italy under IEC and RoHS compliant standards, the breaker assures durability and environmental safety compliance.

Integrated residual current and overcurrent protection in one compact unit. Thermal magnetic tripping with Type C characteristics for reliable fault detection. Dual wiring slots allow flexible cable or busbar connections.

LED status indicators assist with easy fault diagnosis. Toggle switch actuator facilitates manual reset operations. Compliant with IEC standards and RoHS directives for quality and environmental safety. Compact size fits easily into System Pro M Compact® electrical assemblies.
