Molex C-Grid Series Straight Through Hole PCB Socket, 16-Contact, 2 Row, 2.54 mm Pitch, 12A, 350V 90151-2116
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 12A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Bronze |
| Series | C-Grid |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | PCB Receptacle |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 16 |
| Contact Gender | Female |
| Connector System | Board-to-Board, Signal |
| Row Pitch | 2.5mm |
Key Features
- Constructed with polyester housing for durability and electrical insulation.
- Features bronze contact material with tin plating for corrosion resistance.
- Supports a current rating of 12A and voltage rating of 350V.
- Operates within a temperature range of -55°C to 125°C.
- Designed with solder termination and through hole mount type for secure PCB installation.
- Dual row configuration with 16 female contacts ensures reliable connectivity.
- Connector system suitable for board-to-board signal transmission.
Product Description
Molex 90151-2116 C-Grid Series Straight Through Hole PCB Socket is a high-performance PCB receptacle connector featuring 16 contacts arranged in two rows with a 2.54 mm pitch. It is engineered with a robust polyester housing material providing excellent mechanical strength and electrical insulation properties.
The contacts are made of bronze and plated with tin to ensure reliable conductivity and resistance to corrosion, suitable for demanding board-to-board and signal applications where durability and consistent electrical performance are required.
This connector supports a current of 12A and a voltage of 350V, making it suitable for a wide range of electronic and industrial equipment. It has a temperature operating range from -55°C to 125°C, allowing usage in harsh environments including industrial, manufacturing, and telecommunications sectors.
The termination style is solder type paired with a through hole mount which ensures stable mechanical connection to PCB assemblies. Its straight orientation facilitates easy integration in various electronic module designs.
Key features include its dual row 16-contact female configuration and a row pitch of 2.5 mm for compact PCB layout design. This connector is designed without specific certifications but meets general industrial quality standards for electrical connectors.
Polyester housing material ensures durability and electrical insulation. Bronze contacts with tin plating for corrosion resistance. Supports continuous operation from -55°C to 125°C. Rated for 12A current and 350V voltage for diverse applications.
Solder termination and through hole mounting provide reliable PCB integration. Straight orientation optimized for board-to-board signal connections. Dual row, 16 female contacts with 2.54 mm pitch spacing.
This PCB Socket is ideal for industrial, electronic manufacturing, telecommunications, and other commercial electronics applications requiring reliable, high-quality board-to-board connector solutions.
Explore the Electronics Components category on EnvMart for compatible PCB connectors and sockets to complete your hardware assemblies with trusted Molex solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 12A and a voltage rating of 350V.
It operates within a temperature range of -55°C to 125°C, suitable for various environments.
It features 16 female contacts arranged in a dual row configuration.
The contacts have a pitch size of 2.54 mm, allowing for compact PCB layout designs.
It uses a solder termination type, ensuring a secure connection to the PCB.
The housing is constructed from polyester, providing durability and electrical insulation.
The contacts are made of bronze and are plated with tin for corrosion resistance.
It is designed for through hole mounting, which ensures stable mechanical connection to PCB assemblies.
This connector is suitable for board-to-board signal transmission in industrial, manufacturing, and telecommunications sectors.
The connector has a straight orientation, facilitating easy integration into various electronic designs.
The country of origin for this PCB socket is India.
While it does not have specific certifications, it meets general industrial quality standards for electrical connectors.
