Molex Automotive Connector Female Blue Cable 80 Way Crimp Termination 11A 34566-1903
Specifications
| Country of Origin | China |
|---|---|
| Brand | Molex |
| Colour | Blue |
| Current | 11A |
| Height | 47.92mm |
| Depth | 100.8mm |
| IP Rating | IPx9K, IP67 |
| Width | 40.4mm |
| Gender | Female |
| Mount Type | Cable |
| Housing Material | Nylon |
| Contact Material | Copper Alloy |
| Series | 34566 |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Sub Type | Receptacle Housing |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 4 |
| Contact Plating | Gold, Silver, Tin |
| Number of Contacts | 80 |
Key Features
- The connector features a blue nylon housing ensuring durability and resistance.
- It consists of 80 contacts arranged in 4 rows with 2.54mm pitch spacing.
- Termination type is crimp, designed for female gender cable mount applications.
- Rated IPx9K and IP67 for high ingress protection in harsh environments.
- Operating temperature range from -40°C to 125°C for wide temperature applications.
- Contact materials include copper alloy with gold, silver, and tin plating for enhanced conductivity.
- It is compatible with the 34566 series and provides secure mechanical and electrical connection.
- Suitable for automotive and industrial electrical system integration.
Product Description
Molex 34566-1903 is a high-quality automotive connector designed for female cable termination with 80 contacts and an 11A current rating. This product features a robust blue nylon housing and a 2.54mm pitch MX123 female receptacle housing with keying option G and wire dress option 9, ensuring precise and secure connections in demanding automotive and industrial environments.
The connector's termination type is crimp, suitable for cable mount applications, and the contacts are crafted from copper alloy plated with gold, silver, and tin to ensure excellent electrical conductivity and corrosion resistance.
With an ingress protection rating of IPx9K and IP67, this connector is protected against high-pressure water and dust, making it reliable for harsh environmental conditions. It operates within a temperature range of -40°C to 125°C, ideal for a variety of industrial and automotive applications.
The product dimensions are 47.92mm in height, 40.4mm in width, and 100.8mm in depth, making it compact yet robust for effective installation. The connector has 80 contacts arranged in 4 rows for efficient wiring. The blue nylon housing provides mechanical strength and heat resistance.
Crimp termination ensures strong and reliable cable connections. Rated for 11A current ensuring safe electrical performance. Gold, silver, and tin plating on contacts reduce wear and oxidation. IPx9K and IP67 ratings assure performance in moisture and dust-rich environments.
Operating temperature ranges from -40°C to 125°C, suitable for tough industrial conditions. Designed under the 34566 series for compatibility with related components. Perfect for automotive electrical systems, industrial wire harnesses, and machinery.
This automotive connector is an essential component for maintaining high-performance electrical connections in vehicles and industrial equipment. Available exclusively through EnvMart, it ensures reliability and quality for professional engineers and technicians.
Explore more products in our Automotive Electrical Connector category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 11A, ensuring safe electrical performance in various applications.
The operating temperature range is from -40°C to 125°C, making it suitable for a wide variety of environments.
It features 80 contacts arranged in 4 rows, allowing for efficient wiring in applications.
This connector uses crimp termination, designed for secure female cable mount applications.
The contacts are made from copper alloy and are plated with gold, silver, and tin for enhanced conductivity and corrosion resistance.
The dimensions are 47.92mm in height, 40.4mm in width, and 100.8mm in depth, making it compact for installation.
It has an ingress protection rating of IPx9K and IP67, providing high resistance to dust and water ingress.
Yes, it is designed for compatibility with the 34566 series, ensuring secure mechanical and electrical connections.
The housing is made from blue nylon, which provides mechanical strength and heat resistance.
It is suitable for automotive electrical systems, industrial wire harnesses, and machinery integration.
The contacts are arranged with a pitch spacing of 2.54mm, ensuring precise connections.
The country of origin for this connector is China.
